Dual Touch Screen Payment Kiosk with Advertising screen
Key overview:
~ Upper advertising panel helps promote your application to effectively maximize
~ Cash or cashless payment function
Basic Configuration
| ||
Central PC (Customizable) | Motherboard | H61/B75 |
| CPU | Dual core G2030, Main frequency: 3.0 GHz, Interface type: LGA 1155. Optional: i3/i5/i7 | |
| RAM | DDRIII 4G / 8G | |
| HDD | 500G, 7200rpm, 3.5" S-ATA | |
| Inter face | RS-232 Ports; LTP; USB Ports, 10/100M Net Port; Integrated Net Card, Sound Card | |
Monitor | Screen size | 15", 17", 19" 22", etc. |
| Brightness | 300cd/m2 | |
| Contrast | 800:1 | |
| Response time | 5ms | |
| Dot pitch | 0.264mm | |
| Best resolution | 1280x1024 | |
Touch Screen | Screen size | 15", 17", 19" 22", 26", etc. |
| Touch type | SAW, Infrared, Capacitive | |
| Resolution | 4096x4096 | |
| Feature | High transparence, precision and durability | |
Kiosk Enclosure | Material | Cold-rolled steel ST12 SPCC with 1.5mm~2.0mm thickness. |
| Surface finishing | Car painting technology. Steel cabinet sprayed metallic paint, Anti-rust, Anti-acid, Anti-dust. | |
| Color and Logo | Customizable | |
| Features | Easy service access through front or back door. | |
| Accessories | Speakers | Stereo loudspeaker, 8Ω 10W |
| Fans | Internal ventilation system | |
| Power Supply | Input voltage | 100~240V/AC |
| Frequency | 50Hz to 60Hz | |
| Operation System | Windows 2000 / Windows XP / Windows 7 / Vista / Windows 8 / Linux / Android | |
| Package | Safe packing with bubble foam, carton box or plywood case | |
| Safety | Anti-vandal safety; | |
| Electric safety: compliant with GB4943 Standard; | ||
| EMC(Electro Magnetic Compatibility): Compliant with GB9254 and GB/T17626 Standard | ||
| Monitoring system: Digital video security monitoring system (optional) | ||
Data safety: EPP is compliant with VISA Security Standard, PCI compliant (optional) ; Card reader is compliant with EMV Level1 Standard; | ||
Additional Functions Depending on Your Requirements | |||
Printer | Thermal printer | 58mm/76mm/80mm/112mm paper width RS-232 / USB interface | |
Laser Printer | A4/A6 laser printer (Black & White and color) | ||
Card Reader | Magnetic Card Reader | Magnetic card (Tr 1/2/3) compliant with ISO and compatibility standard | |
Chip Card Reader | Chip card reader, Compliant with EMV standard, IC card reading and writing | ||
RFID Card Reader | Contact / Contactless card reader | ||
Keyboard | 3DES Metal EPP; 16 keys, waterproof, dustproof, vandal proof IP65 | ||
64bits metal keyboard with trackball / touchpad | |||
Bar Code Scanner | 1D barcode scanner (Honeywell /Barcode Hand Scanner...etc), single-line scanner, multi-line barcode scanner | ||
QR / 2D code scanner(Honeywell brand) | |||
Payment Parts | Cash validator (ITL, MEI, Cashcode, Moneycontrol, NRI, JCM...etc) | ||
Coin Validator (ITL, MEI, NRI, ICT...etc) | |||
Coin Dispenser (ITL, MEI, NRI, ICT...etc) | |||
Other Peripherals | wifi/GPRS/Webcamera/UPS/3G/ Card Dispenser / Identity recoginition modules | ||
Card Dispenser | card thickness:0.4-1.2mm, multi card box capacity,card volumn alarm function etc | ||
All SDK are free of charge
Shipping
Sample 3-7 days to the World by air or DHL/Fedex etc express
bulk order to the world by sea or air upon the country
- Fast response: Our Sales representative will respond your inquries within 12 working hours;
- Pre sales technical consultation: Our engineer team has more than 10-year experiences in kiosk industry, we will always offer you suitable solutions according to requirements;
- Software development support: We provide API for all the components to support software development, and we could also provide software developing service if you could provide necessary APIs
- Fast and on time delivery: We guarranty on time delivery, you could receive goods at expected time;
- Warranty: free warranty for 12 months, and lifetime maintenance support.
