Automatic Beverage PET Bottle Unscrambler

Specifications

automatic beverage PET bottle unscrambler specification:

Model: LP-18

Parameter

l. Unscramble Heads:       18pcs

2. Capacity:                    10000-12000b/h

3. Suitable to bottles:        Adaptive bottle:dia.50-100,height165-330

4. Air Pressure Required   0.7mpa

5. Total Power                 2.25kw

6. Machine Weight           3200kg

7. Machine Dimension      2200MM in diameter and 2300MM in height

automatic beverage PET bottle unscrambler features:

1. Famous Mitsubishi brand PLC and Touch-screen Control Panel, easy operate, full-automatic working

2. Output capacity adjustable

3. Torque limit part is designed for the main motor reducer so as to protect the machinery if malfunctions occur.

4. Two put-casts in one cycle ensure that every work location should be with one bottle, which enhances bottle output efficiency.

5. The bottles are neck locked through the air conveyor so as to avoid overturn in delivery.

6. Dilapidated bottles will be eliminated by a special device.

7. A lock detector is equipped for alarming; when locked, the machine will automatically stop.

8. A photoelectric switch is set for starting when there is no bottle and stopping when there are bottles.

9. An oil pump will readily fill up the gears, bearings and the cams

10. Maintenance doors and mould replacement door provided.

11. Machine outer tank and Revolving tank and meet the bottle part are all stainless steel AISI304. Frame part adopts high-grade carbon jointing.

12. Adopted famous Mitsubishi, Omron electric parts.

automatic beverage PET bottle unscrambler Pictures
