Refrigeration bath heater bath thermostat oven constant temperature unit thermostatic chiller FC series Immersion cooler
- 0 per Month
- Shanghai
-
-40~200degree Heating and cooling systems,Refrigerated heating circulator
-
deep low temp cooling circulator Low temperature chiller cooling freezer cooling only circulation cool pump -105 to -60 degree
-
CE mechanical refrigeration circulator Refrigeration typ water chiller freeze Cooling circulator refrigeration type cooler
-
mechanical refrigeration heat cooling chamber Refrigeration typ water chiller freeze Cooling circulator FL-series 7 to 30 degree
-
CE Cooling thermostat bath circulators Low temperature chiller display cooling freezer LT-A series -105 to -60 degree
-
CE Laser Equipment Cooling water chiller low temperature froze hypothermia cool Cooling circulators LT series -125 to -20 degree
Product Details
| Condition: | New | Automatic Grade: | Automatic | Type: | Other |
| Place of Origin: | Jiangsu, China | Brand Name: | LNEYA | Model Number: | FC series |
| Voltage: | 220V,380V | Power(W): | 50HZ,60HZ | Warranty: | 1 year |
| After-sales Service Provided: | Overseas third-party support available |
Product Description
Specifications
Temperature rang:-20 to 200 degree,-40 to 200,-60 to 200With self-diagnosis function.
Touch screen display,PID PLC
Description:
It is widely applied to the field of bioengineer, medicine, food, chemical industry, metallurgy and petroleum, offering ideal constant temperature Equipment for the research institute, high-education institute, quality Control department and lab of the factory.
Features:
1. With self-diagnosis function, freezer overload protection, high pressure switches, overload relays, thermal protection device and other security functions.
2. Use the French compressor Tecumseh, filter drier Danfoss, solenoid valve Emerson, expansion valve.
3. LED display, clear, easy to operate.
4. Succeed in making the temperature decrease successively.
5. The liquid container is made by stainless steel, the volume is very suitable.
6. Adopt the environmental refrigerant to meet environmental requirements without using fluorine.
7. Multi-safety protection, more reliable operation.
8. Use the pump stir up to make the temperature in the container uniformly.
9. The function of correcting the temperature.
10. Independent automatic overheat preventive device.
Technical Parameters:
Model | FC-1020 | FC-2020 | FC-1040 | FC-2040 | FC-1060 | FC-2060 | |
Temperature range | -20.00℃~200.00℃ | -40.00℃~200.00℃ | -60.00℃~200.00℃ | ||||
Temperature accuracy | ±0.03℃ | ||||||
Temperature resolution | 0.01K | ||||||
Volume of container | 25*20*20 | 40*25*20 | 25*20*20 | 40*25*20 | 25*20*20 | 40*25*20 | |
Tank volume | 10L | 20L | 10L | 20L | 10L | 20L | |
Way of temperature control | PID adaptive controller | ||||||
Way of circulation | 20L/min,1bar The default is internal recycle, it can be made with external recycle mode. | ||||||
Input and display | 7-inch color touch screen display | ||||||
Data record | Temperature curve record, data export to excel format and USB output interface | ||||||
Function of alarm | Over-temperature alarm, sensor alarm, independent automatic overheat preventive device and alarm for refrigerator abnormity. | ||||||
Sensor | PT100 | ||||||
Heating power | 1200W | 2500W | 1200W | 2500W | 1200W | 2500W | |
Cooling power | 200℃ | 1200W | 2500W | 1200W | 2500W | 1200W | 2500W |
50℃ | 1200W | 2500W | 1200W | 2500W | 1200W | 2500W | |
20℃ | 1200W | 2500W | 1200W | 2500W | 1200W | 2500W | |
0℃ | 1200W | 2500W | 1200W | 2500W | 1200W | 2500W | |
-10℃ | 600W | 1250W | 1200W | 2000W | 1200W | 2500W | |
-25℃ |
|
| 720W | 1200W | 1200W | 2500W | |
-35℃ |
|
| 380W | 800W | 960W | 2000W | |
-55℃ |
|
|
|
| 400W | 900W | |
Material | SUS304 | ||||||
Case material | SUS304 | ||||||
Circulation connection size | External cycle connection size M24*1.5 | ||||||
Compressor | Embraco | ||||||
Dry filter | Danfoss | ||||||
Expansion valve | Danfoss | ||||||
Refrigerants | R404A | R404A R508B | |||||
Size | 45*55*85 | 50*65*95 | 45*55*105 | 50*65*125 | 45*55*135 | 50*65*145 | |
Power | 220V 50HZ 2500W max | 220V 50HZ 4000W max | 220V 50HZ 2700W max | 220V 50HZ 4300W max | 220V 50HZ 3000W max | 220V 50HZ 5000 Wmax | |
Weight | 85kg | 100kg | 130kg | 150kg | 145kg | 185kg | |
