10/100M indoor type EOC master

Name: 10/100M indoor type EOC master
Brand: HiOSO
Availability: InStock

FOB Price

USD $50 - $100 / Piece

1 Piece(Min.Order)

Supply Ability 10000 Set / Sets per Month
Port Shenzhen
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Guangdong, China

Brand Name:

HiOSO

Model Number:

HA3200

Product Description

Profile

HA3200 EOC master is single-channel-100M indoor equipment, with carrying capacity of 253 EOC slaves. It can work in atrocious weather with good stability because of its waterproof and lightproof shell.

Character

Good anti-jamming capability with OFDM (kind of MCM, Multi-Carrier Modulation) and channel-adaptive technology.

Highly adaptable to network, amplifier and distributor.

Highly effective filter, lower interference to CATV

Supply VLAN, IGMP and QoS

Support SNMP, WEB and CLI management

Support remote software upgrade

Support integrated management for slaves

Support AC220V and AC60V power supply

Technical Specification

Parameter	Specification
System Bandwidth	Physical layer data rate 224Mbps IP data throughput 100Mbps
Modulation	BSPK, QPSK, 1024/256/64/16/8-QAM, ROBO
MAC Protocol	TDMA and CSMA
EOC technology	HomePlug AV
Frequency	7.5 ~ 30MHz
Protocol and Standard	IEEE 802.1Q IGMP v1, v2 IEEE 802.1P QoS
NMS	WEB CLI SNMP
Data Interface	Two 10/100Base-TX RJ45 input port Auto MDI/MDIX Comply with 802.3, IEEE802.3u
TV Interface	Two RF ports Imperial or Metric thread F type Output level: 108dBμV Insertion Loss: <1dB Impedance: 75Ω
Hybrid Interface	One RF hybrid signal output port Imperial or Metric thread F type Frequency: 2-870MHz Output Level: 108dBμV Impedance: 75Ω
Light Indicator	LINK (link LED) ETH (Ethernet port LED) Sys (system LED) PWR (power LED)
Distance	>700m

Working Environment

Power	AC220V /AC60V
Power Consumption	<6W
Dimension	216mm(length) × 178mm(width)× 38mm(height)
Working Temperature	-20°C ~ +80°C
Storage Temp	-25°C ~ + 75°C
Humidity	20% ~ 85%(non-condensing)
Storage Humidity	10% ~ 90%(non-condensing)

Certificates
