small uv flatbed printer machine for glass,ceramic(UVC0906)

FOB Price

USD $10,000 - $14,000 / Set

1 Set(Min.Order)

Supply Ability 2500 Set / Sets per Month
Port Dalian(China)
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Plate Type	Flatbed Printer
Place of Origin	Liaoning, China	Brand Name	zhongye
Model Number	UVC-SK0906	Usage	Other, KT board,KT board,glass,wooden,ceramic,and so on
Automatic Grade	Automatic	Gross Power	1500w
Dimensions(LWH)	2.9m1.3m1.3m

Product Description

Specifications

UVC0906
(1)Super quality and competitive price
(2) one year guaranty
(3)lifetime maintain, 24 hours online technical support

UVC-0906 is a small size UV flatbed printer,It adopts Epson print heads,equipped with double servo drivers, specialized in printing sheet to sheet. Media is located on printer flatbed and the printer flatbed move on two rails to finish printing. Print height reach 8cm maximum

It replaces the traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility

Print Head: Siko or Epson DX5, Print size: 0.80m*0.55m Colour: CMYK or CMYK W or CMYK LC LM W

Drying system:LED lamp

Usage:KT board,PVC board,Plexiglass board,glass board,ceramic board,tile,metal board,leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl ect

Details

Name:	UVC-EP0906
Class:	UVC series
Print technology:	Drop-on-demand Piezo electric
Printhead:	1/2(Epson DX5)
Print width:	0.80m*0.55m
Print height:	8cm
Resolution:	1440dpi max
Speed:	1head: 2pass 25sqm/h; 4pass 16sqm/h; 6pass 10sqm/h 2heads: 2pass 50sqm/h; 4pass 32sqm/h; 6pass 20sqm/h
Locating mode:	Raster /servo
Color:	CMYK
Media width:	0.90m*0.60m
Media handle:	Sheet to sheet
Media types:	KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc
Drying system:	LED lamp
File format:	TIFF,Postscript 3,JPEG,EPS,PDF
Working process:	Printmon software for windows xp
Rip:	Photoprint /maintop
Power supply:	50hz/60hz 220v(10%)20A
Operation enviroment:	(Temperature )18-26(Humidity )40%-70%
Dimension:	2.9m1.3m1.3m
Weight:	700KG
