Home > Products > UV Flatbed Printer > 1.8m UV flatbed printer with white ink high resolution
1.8m UV flatbed printer with white ink high resolution
- 150 Set / Sets per Month
- Dalian
- T/T Credit Card
Product Details
| Condition: | New | Plate Type: | Flatbed Printer | Place of Origin: | Liaoning, China |
| Brand Name: | ZhongYe | Model Number: | UVE1800 | Automatic Grade: | Automatic |
| Dimensions(L*W*H): | 2.84m*0.9m*1.25m | Weight: | 160Kg/240Kg | Certification: | CE ISO |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Roll to roll Sheet to sheet digital printing machine.We have 3.2m, 2.5m, 1.8m, can be with 2 groups Epson DX5 head (1 group optional), 2880dpi Color CMYK/CMYK W
Summary
Zhongye UVE Series(UV Economical Series) printers: Adopting Epson DX5 print heads, UV LED drying system, steel belt DC driver, (alternative option:Guide rail, AC servo driver), working with UV ink, widely used for KT board, paper board, PVC board, PS board, glass, ceramics, metal board, etc. All flat boards and roll to roll printing materials.
Features:
1.UV technology
2.Economical price and ingenious design
3.UV LED drying systerm, best and fast drying and curing. Even materials which cannot bear high temperature can also be printed very well
4.With both roll-to-roll and sheet-to-sheet media handling system, it is a real muti-functional UV printing equipment
5.No need negative-pressure systerm, easier operation
6.High resolution
After sold service
1.Anytime on line technology support
support
3.send the technician to your place for helping
Technical parameter
Print technology: | micro piezo dot-on-demand |
Print head: | 2 groups Epson DX5 Printheads (paratactic structure) (1 group optional) |
Media thickness | 2cm |
Printing width | 1.8m |
Resolution: | 2880dpi max |
Speed: | Draft Model: 540*720dpi 28sq.m./h Production model: 720*720dpi 16sq. m. /h High quality model: 720*1440dpi 9sq. m./h |
Ink | Eco-solvent Inks Ink Cartridge: 350ml, 8pieces |
Locating mode: | Raster /servo |
Color: | CMYK/CMYK W |
Media width: | 1.8m |
Media handle: | Roll to Roll; Sheet to Sheet |
Media types: | KT board; PVC board; Plexiglass board; glass board; ceramic board, tile; metal board; leather, etc. all flat materials and all the roll to roll materials like flex banner, mesh, one way vision, vinyl,etc |
Drying system: | Front, back heating system(middle heating system is optional), middle flatbed sucker system, PID temperature; UV LED |
File format: | TIFF, JPEG etc |
Working process: | Professional bi-language software (Chineses&English) |
Rip: | Photoprint /maintop |
Power supply: | AC 220-240v 50/60 HZ |
Operation enviroment: | 1000W(max. power) 300W(normal working power) Temperature: 20-25°C Humidity: 40-70%, non condensation |
Dimension: | 2.84m*0.9m*1.25m |
Weight: | 160KG/240KG |
If you are intersted in our products, pls do feel free to contact with me.
