Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | YZPST | Model Number: | RX27-1-7W-6K8-J-10 |
| Type: | Other, cement resistor | Technology: | Carbon Composition | Package Type: | Throught Hole |
| Resistance: | 6K8 | Rated Power: | 7W | Temperature Coefficient: | T.C.R. ≤350ppm/℃ |
| Operating Temperature: | -55℃ ~ +155℃ |
Product Description
CEMENT RESISTOR
RX27-1-7W- 6K8-J
3 Performance:
Description | Performance Requirements | Test Method | |
Resistance Temperature Coefficient | T.C.R. ≤350ppm/℃ | Test temperature +20℃/-55℃/+20℃/+125℃/+20℃ | |
Short-time Overload | R≤±(1%R±0.05R) No visible damage,Markings legible | 2.5 times rated voltage or maximum overload voltage (the lower) 5 seconds | |
Wiith Standing Voltage | No flasheover or breakdown | AC 700V 1 minute | |
Terminal Strength | Pulled | R≤±(1%R+0.05R) No visible damage | Φd 0.68mm;Load 20N 10s |
Winded |
Φd 0.68mm;Load 20N 900 | ||
Twisted | 3600 in opposite direction | ||
Resistance to Vibration | R≤±(1%+0.05R) No visible damage | 3 direction 2 hours each | |
Solder-heat Resistance | R≤±(1%R+0.05R) Marks legible ,no visible damage | 350℃ 2mm from the body,3 seconds | |
Solderability | At least 95% of the dipping surface must be covered by new solder, no flaws gathered. | 235℃ 2mm from the body, 2 seconds | |
Temperature Cycle | R≤±(1%R+0.05R) No visible damage | -25/+155℃ for 5 cycles | |
Humidity | R≤±(5%R+0.05R) No visible damage | 40℃ 95%RH 1344 hours | |
70℃ Load Life | R≤±(5%R+0.1R) No visible damage, marks legible | rated voltage or maximum voltage,1.5 hours on, 0.5 hours off, 70 centigrade temperature 1000 hours | |
