Home > Products > New Products > Diagonal Mono-Layer sheet plastic extrusion machine
Diagonal Mono-Layer sheet plastic extrusion machine
- 10 Set / Sets per Month
- SHANGHAI
- T/T Credit Card PayPal
Product Details
| Condition: | New | Application: | Sheet | Plastic Processed: | PP |
| Screw Design: | Single-screw | Place of Origin: | Jiangsu, China | Brand Name: | riyi |
| Model Number: | 660PC |
Product Description
Specifications
Plastic Sheet Extrusion machineDiagonal Mono-Layer Plastic Sheet Extruder
PP/PS/PE plastic sheet
Plastic Sheet Extrusion machine
--The machine is a combination of extruder, calendar, rewinder and eletric control cabinet, etc.
--The main parts, such as screw, barrel, screen exchanger, T-die adopt superior alloy steel(38CrMoAIA) with high hardness, strong corrosion resistance and lon operating life after nitrogen treatment.
--The special designed screw adopts big L/D Ratio to ensure the good plasticing, stable extrusion and high output.
--Non-stop fast screen changer with double-sieve is controlled by hydraulic unit, which operation is easy and enhances the production efficiency.
Technical Parameter:
| Model | 90 | 105 | 110 | 120 |
| Material Used | PP, PS, HIPS, PE | |||
| Sheet Width | ≤ 680mm | ≤ 680mm | ≤ 680mm | ≤ 680mm |
| Sheet Thickness | 0.3-2.0mm | 0.3-2.0mm | 0.3-2.0mm | 0.3-2.0mm |
| Layer | 1 | 1 | 1 | 1 |
| Extrusion Capacity | ≤ 100Kg/h | ≤ 150Kg/h | ≤ 200Kg/h | ≤ 250Kg/h |
| Screw Dia. | 90mm | 105 | 110 | 120 |
| L/D Ratio | 28: 1 | 32: 1 | 32: 1 | 33: 1 |
| Roller Dia. | 300mm | 350mm | 350mm | 400mm |
| T-die Width | 800mm | 800mm | 800mm | 800mm |
| Motor Power | 37KW | 45KW | 55KW | 75KW |
| Overall Power | 90KW | 100KW | 120 KW | 150 KW |
| Overall Dimension | 10.5*1.8*2.2 | 10.5*1.8*2.2 | 11.5*1.8*2.2 | 12.0*2.0*2.2 |
| Weight | 5.0T | 5.5T | 6.0T | 6.5T |
| Power Supply | 380V/50HZ, Tri-phase, Four-wire | |||
