Suitable for Rubber Machinery CNC Horizontal Lathe with High Quality Headstock
- 10 Set / Sets per Month
- qingdao
- T/T
- Suitable for Mine Machinery CNC Horizontal Lathe
- Semi-automatic Application to Automobile Manufacturing Horizontal Lathe
- Suitable for Various Idustries CNC Facing Heavy Duty Horizontal Lathe
- Application to Processing Propeller Horizontal Lathe
- China Wholesale Top Quality Large Diameter Horizontal Lathe for Machinery
- Application to Processing Large Diameter Tire Mold CNC Horizontal Lathe
Product Details
Condition: | New | Type: | Other, Horizontal Lathe | CNC or Not: | Normal |
Automatic Grade: | Semi-Automatic | Max. Swing Diameter: | 1500mm | Place of Origin: | Shandong, China |
Brand Name: | Shengtuo | Model Number: | CW61125 | Voltage: | 380V |
Power(W): | 11KW | Dimension(L*W*H): | 2700*1800*1800mm | Weight: | 8 ton |
Certification: | CE ISO9100 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Suitable for Rubber Machinery CNC Horizontal Lathe with High Quality Headstock
This kind of machine is for cutting and processing various metal workpieces. It is widely applied to many industries,such as rubber machinery,mine machinery textile machinery,chemical machinery ,automobile manufacturing and so on. And it is mostly used to process large-diameter tire moulds ,large-diameter flanges, various valves and pipelines, pressure vessels, screw propeller,steamer machine accessories and other workpieces.
Specifications:
Item | ST-CW61140 | Unit |
Max.swing diameter of workpiece | 1500 | mm |
The cross-feed travel of slide carriage | 700 | mm |
The longitude-feed travel of slide carriage | 700 | mm |
Maximum swing of work piece over bed | 1400 | mm |
Maximum swing over slide carriage | 750 | mm |
Max.length of workpiece | 700 | mm |
Max.weight of workpiece | 2500 | kg |
Chuck diameter | 1200 | mm |
The quantity of the chunk jaws | 4 | set |
Number of spindle speeds | 6 | level |
The spindle diameter | 220 | mm |
Spindle bore | 50 | mm |
Cutter bar section size | 50×50 | mm |
Spindle speed range | 13~103 | r/min |
Guideway width | 850 | mm |
Power of main motor | 11 | KW |
Power of feed motor:1.1kw | 1.1 | KW |
Adjusting mode of feed motor | stepless |
|
Machine power supply | 380v,50HZ,3P | |
Overall dimensions | 2700×1800×1800 | mm |
Lathe weight | abouit 8 | t |
Standard configuration: 1 set of headstock,1 bed and 1 set of carriage, 1 piece of chuckΦ1200mm with 4 jaws(350mm-long per jaw),1 tailstock,1pieces of chuck wrenche. | ||
Optional Configuration:1 piece of chuck Φ1000mmwiht 3 jaws or 4 jaws,1 main motor(11kw level6), 1 extended bed,1 CNC system,Digital display system. | ||
Specific Notice:Customers can customize the lathes according to their workpieces.(Based on changing configuration). |
Qingdao Shengtuo Machine Tool Co.,Ltd is specialied in manufacturing large -diameter surfacing lathes.The major products are heavy duty landing lathes,horizontal lathes,vertical lathes,CNC,heavy duty lathes,flange lathes,roll turning lathes.We owned the certificate of CE and ISO9100.
It is widely applied to many industries,such as rubber machinery,textile machinery,mine machinery,chemical machinery, Air Accessories,paper machinery, Boiler and Pressure Vessel,wind power accessories and other processing various flanges.
1. Are you a factory or trading company ?
RE: Shengtuo was founded in 1998 and has a history nearly 20 years in manufacturing lathes. Through reformation we have been changed from a state-owned enterprise to a joint-stock private enterprise. In 2008, we began to explore overseas market step by step. Gradually, our partners from around the world become more and more. We believe that a brighter further is waiting for us.
2. What's your advantage?
RE: We have strong R&D ability which can support us to offer "Turnkey Engineering Service"
-Technology Assessment;
- Process Analysis
- Jigs planning
- Production process
- Trial cut processing
- Education & Training
- 24hours service
3. Question : Where is your factory located ? How can I visit there ?
RE: We are located in Qingdao City. Which is only 30 minutes away from Qingdao Airport.
