Home > Products > New Products > National Instruments GPIB-120A Bus Expander / Isolator
National Instruments GPIB-120A Bus Expander / Isolator
Negotiable
1 (Min.Order)
- 0 per Month
You May Like
Product Details
| Place of Origin | Florida, United States | Brand Name | National Instruments | |
| Model Number | GPIB-120A |
Product Description
Specifications
National Instruments GPIB-120A Bus Expander / IsolatorItem was pulled from a working Lab Environment, no further testing has been done.
The National Instruments GPIB-120A is a GPIB expander / isolator. The IEEE 488.1 standard prescribes a maximum of 15 electrical device interface loads in a GPI system. The National Instruments GPIB-120A increases the maximum number of GPIB system devices from 15 to 28. The GPIB-120A is also useful in test and measurement systems because it provides an electrically isolated interface to one or more devices. The GPIB-120A is software transparent; you do not need to rewrite your application software.
Features include:
- Expands the number of GPIB devices to 28
- Bidirectional expansion - Controllers, Talkers, and Listeners can exist on either side of the expansion
- 400 Vrms electrical isolation between GPIB systems for 1 minute
- Software transparent – no software modifications required
- Signal buffering extends the maximum GPIB cable limit to 40 m (device load every 2 m of bus cable)
- Built-in 120 or 240 VAC power supply
- Meets FCC Class A electromagnetic noise emission requirements
