Home > Products > Gabion Box and Mattress > Hot Dipped Galvanized Hexagonal Gabion Basket
Hot Dipped Galvanized Hexagonal Gabion Basket
- 5000 Square Meter / Square Meters per Month
- Shanghai
- T/T
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | Konson | Model Number: | KS-Gabion |
| Material: | Other, Galvanized Iron Wire, Plastic Coated Iron Wire | Type: | Other, Twist hexagonal wire mesh | Application: | Gabions |
| Hole Shape: | Hexagonal | Aperture: | 60*80;80*100;100*120;120*150 | Wire Gauge: | 2.0-4.0mm |
Product Description
Specifications
Hot Dipped Galvanized Hexagonal Gabion Basket1 CE,ISO9001,SGS
2 PVC Coated Gabion box
3 Wire dia.2.0-4.0mm
4 Many sizes
1. Introdution
Hot Dipped Galvanized Hexagonal Gabion Basket
Hot Dipped Galvanized Hexagonal Gabion Basket can be design as your request. It is the most common and most practical kind that is used in the project.
Filled with stones at the river bank or seaside, it can be used to stop flood, and prevent the rock on the mountain from falling. Steel wire used is hot-dip galvanized or galfan(zinc 95%, aluminum 5%). If it is required, 0.5 mm PVC is then coated on the galvanized/galfan wire to provide protection when used in aggressive environment.
Hot Dipped Galvanized Hexagonal Gabion Basket can withstand acid soils, salt or fresh water or wherever the risk of errosion. In order to reinforce the structure, the edge wire has a greater diameter than the mesh wire.
Hot Dipped Galvanized Hexagonal Gabion Basket is divided into units by means of diaphragms positioned at approximately 1m centre.
We mainly export gabions to Western Europe, Mid-South America, Southeast Asia etc..
U2. Flood bank or guiding bank
U3. Prevention of rock breaking
U4. Water and soil protection
U5. Bridge protection
U6. Strengthening structure of soil
U7. Protection engineering of seaside area
U8. Seaport engineering
U9. Isolation walls
U10. Protection of road
Length (m) | width (m) | height (m) | diaphragm | volume | tolerance |
2 | 1 | 0.3 | 1 | 0.6 | Length+/-3% |
3 | 1 | 0.3 | 2 | 0.9 | |
4 | 1 | 0.3 | 3 | 1.2 | |
2 | 1 | 0.5 | 1 | 1 | |
3 | 1 | 0.5 | 2 | 1.5 | |
4 | 1 | 0.5 | 3 | 2 | |
1 | 1 | 0.5 | 0 | 1 | |
1.5 | 1 | 1 | 0 | 1.5 | |
2 | 1 | 1 | 1 | 2 | |
3 | 1 | 1 | 2 | 3 | |
4 | 1 | 1 | 3 | 4 |
C2. Construction is simple, without special skills.
C3. A strong withstand natural damage and corrosion resistance and resistance to adverse effects of climate.
C4. Withstand large-scale deformation, and does not collapse.
C5. Cage rock crevice between the mud to plant production, with the surrounding natural environment melting together.
C6. Has good permeability to prevent static fluid from the damage caused.
C7. Save transportation costs. Can be folded up and assembled on site.
6. Packing and shipping
7. Our services
S1. We can offer any sizes of gabion mesh, baskets or boxes according to the requirements of customers.
S2. We will reply you as soon as possible upon receving your request of your products.
S3. We can provide you with samples free of charge.
8. Company Information
Konson Industrial Company Limited, with more than 15 years production experience, becomes one of the leading manufacturers of the gabions, mattress and gabion production line in China. We would like to offer good service and excellent products to customers wholeheartedly!
The company, with more than 100 experienced employees, has two workshops, one is for the gabion machine making, the other is for the gabion&mattress making. It has a production facility of more than 10 complete sets of gabion production line and four million square meters hexagonal wire mesh(gabion box) each year.
9. Related Photos
