171LB.CR,175LB.CR SPLICE BAR
USD $5 - $30
/ Piece
500 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- Tianjin Shanghai
- T/T
You May Like
Product Details
| Type: | Other, splice bar | Material: | AREMA GRADE/STEEL GRADE 55# | Dimensions (L x W x H) (mm): | according to standards and custumers' requirements |
| Place of Origin: | Henan, China | Brand Name: | LT | Model Number: | 171LB.CR SPLICE BAR,175LB.CR SPLICE BAR |
Product Description
Specifications
AREMA SPLICE BAR STANDARD:AREMA 2007.SPECIFICATION:171LB.CR SPLICE BAR,175LB.CR SPLICE BAR.
We specialize in producing all kinds of railway products such as splice bars,fish bolts,gauge aprons,screw spikes,elastic clips,rubber tie plates,gauge ties,etc.
We are always keeping providing better products and higher-class service to satisfy our customers.
Splice bars are used to joint or connect two rails together, and splice bars are also called as rail fishplates or rail splice bars.
Splice bars we can provided as below:
AREMA standard splice bar: 171LB.CR splice bar,175LB.CR splice bar.
| CHINESE STANDARD SPLICE BAR | |||||||||
| SIZE | STANDARD | MATERIAL | |||||||
| 43KG | TB/T2345-2008 | B7 | |||||||
| 50KG | |||||||||
| 60KG | |||||||||
| 75KG | |||||||||
| BS STANDARD SPLICE BAR | |||||||||
| SIZE | STANDARD | MATERAIL | |||||||
| BS75R | BS47-1 | EUROPEAN GRADE 700 | |||||||
| BS80A | |||||||||
| BS90A | |||||||||
| BS100A | |||||||||
| BS113A | |||||||||
| SPLICE BAR FOR JIS E STANDARD RAIL | |||||||||
| RAIL SIZE | SPLICE BAR STANDARD | SPLICE BAR MATERIAL | |||||||
| 37A | JIS E 1102-2001 | SS490,S20C | |||||||
| 50N | |||||||||
| CR73 | |||||||||
| CR100 | |||||||||
| SPLICE BAR FOR AREMA 2007 STANDARD STEEL RAIL | |||||||||
| T-RAIL | STANDARD | MATERIAL | HOLE DIAMETER | ||||||
| 100LB.ASCE | AREMA 2007 | AREMA GRADE/STEEL GRADE 55# | 1.1875" | ||||||
| 115RE | 1.1876" | ||||||||
| 132RE | 1.13125" | ||||||||
| 136RE | 1.13126" | ||||||||
| SPLICE BAR FOR CRANE RAIL | |||||||||
| 104LB.CR | AREMA 2007 | AREMA GRADE/STEEL GRADE 55# | 1.0625" | ||||||
| 105LB.CR | 1.3125" | ||||||||
| 135LB.CR | 1.1875" | ||||||||
| 171LB.CR | 1.1875" | ||||||||
| 175LB.CR | 1.1875" | ||||||||
| STANDARD LENGTH:914.4MM | |||||||||
| THE BOLT HOLES ARE EITHER DRILLED OR PUNCHED,WITH 4 AND 6 HOLES AVAILABLE. | |||||||||
| SPLICE BAR FOR UIC STANDARD STEEL RAIL | CORRESPONDING RAIL | ||||||||
| SIZE | WEIGHT(KG/M) | DIMENSION(MM) | MATERAIL | SIZE | WEIGHT(KG/M) | STANDARD | |||
| a | b | c | X | ||||||
| U79 | 23.92 | 109 | 27 | 41 | 2.75 | GRADE 700 | UIC54 | 54.43 | UIC |
| 2.75 | |||||||||
| U85 | 29.68 | 121 | 24 | 45 | 2.75 | GRADE 700 | UIC60 | 60.34 | UIC |
| 2.75 | |||||||||
| SPLICE BAR FOR DIN STANDARD STEEL RAIL | CORRESPONDING RAIL | ||||||||
| SIZE | WEIGTH(KG/M) | DIMENSION(MM) | MATERAIL | SIZE | WEIGHT(KG/M) | STANDARD | |||
| a | b | c | x | ||||||
| y | |||||||||
| F130 | 9.6 | 70 | 16 | 21 | 4.33 | GRADE 700 | S30 | 30.03 | DIN5901 |
| 4.33 | |||||||||
| F133 | 12.7 | 91 | 18 | 20 | 4 | GRADE 700 | S33 | 33.47 | DIN5901 |
| 4 | |||||||||
| F141 | 15.7 | 94 | 20 | 31 | 3 | GRADE 700 | S41 | 41.38 | DIN5901 |
| F149 | 3 | S49 | 49.43 | ||||||
| SPLICE BAR STANDARD:DIN5902:1995 | |||||||||
