Home > Products > New Products > Low price 4 axis cnc wood engraving machine cnc engraving machine 6090
Low price 4 axis cnc wood engraving machine cnc engraving machine 6090
- 230 Set / Sets per Month
- Qingdao
- T/T Credit Card PayPal
You May Like
-
chocolate model cnc engraving machine wood cnc engraving machine 1212
-
cnc woodworking carving machine cnc wood carving machine for sale
-
cnc router wood carving machine cheap cnc wood carving machine
-
cnc metal engraving machine 6090/9015/1325 coin engraving machine
-
multi-purpose cnc engraving machine 1530 engraving machine for stainless steel
-
cnc stone carving machine stone carving cnc machine tools
Product Details
Condition | New | CNC or Not | CNC | |
Place of Origin | Shandong, China | Brand Name | MAN | |
Model Number | MN-6090 | Voltage | 220V/380V | |
Power(W) | 1.5KW | Dimension(L*W*H) | 600*900*100mm | |
Weight | 800kg | Certification | CE ISO | |
Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Low price 4 axis cnc wood engraving machine cnc engraving machine 6090
Product Description
Technical Parameter |
|
|
|
TYPE | 6090 | ||
X,Y Working Area | 600mm*900mm | ||
Z Working Area | ≥80mm | ||
Max. Running Speed | 5-6m/min | ||
Max.Working Speed | 3-4m/min | ||
Max. feeding height | 100mm | ||
Positioning Precision | 0.03mm | ||
Repeating Positioning Precision | 0.02mm | ||
Operation Command | G Code*.u00*.mmg*.plt | ||
Operation System
| NC Studio (PCI card control) | ||
Spindle RMP | 0-24000rpm/min | ||
Collet | 3.175mm, 4 & 6mm | ||
Power of Spindle Motor | 1.5kw/2.2kw Water-cooling | ||
Voltage | AC220V/50HZ, AC110V/60HZ | ||
X, Y and Z axis Driver | 6Amp Stepper Motor | ||
Drive Type | Stepper Motor | ||
Power (Without the spindle power) | 400w | ||
Software Running Environment | Windows xp/Windows7/8 | ||
CAD/CAM Software with machine | UcanCam V8 / Type3 (Free of Charge) | ||
Compatible Software | Type3, Artcam, Castmate, etc. | ||
Machine Dimension | 1300mm * 1100mm * 1500mm | ||
Package Dimension | 1550 * 1215mm * 1770mm | ||
Optional Device | Spray Cooling System | ||
Dust Collecting System | |||
1.5KW/2.2KW water-cooling spindle motor | |||
DSP Hand Held Controller--Offline Control | |||
Z axis Tool Sensor |
Scope of application
1.Wooden areas: main used in redwood classical and antique furniture, wood carving, gifts wooden box, redwood jewelry boxes, ink-stone cutting, decorative products sculpture, fine jewelry carving.
2.Advertising: used in producing all models. Such as company plate, sings, building models, emblem, badge, display panels, fair signs, building numbers, signs of decoration, furniture and other decoration.
3. The machine is suitable for acrylic,PVC,wood,marble etc. Power cutting,3D characters and enchase production etc..
4. Fast speed,suitable for larger Characters processing, relief processingand 3D processing etc..
5.Others: the machine is also can be used in portraits, landscapes, calligraphy lettering, seal carving and other plane surface carving, basso-relieve
Sample
After-sale Service:
1. our technicans will provide on-site service to customers in china. We will supply the whold day online service to foreign customer. According to foreign customer's requirement, we will arrange technicans go abord to install or maintenance the machine
2. within the warranty period and the machine parts damage under normal using condition, we will offer new ones for free for replacement
3. We will offer software upgrade for free for life
4. after the expiry of warranty, we can renewal of the contract, which can enjoy the same service that during the waranty period
5. our company will research the staffs service attitude aperiodically to improve the service satisfaction
