SC706-3MRQ cooker hood piano switch

Name: SC706-3MRQ cooker hood piano switch
Brand: BAOKEZHEN
Availability: InStock

FOB Price

USD $1.10 - $1.10 / Piece

10000 Pieces(Min.Order)

Supply Ability 200000 Piece / Pieces per Month
Port Shenzhen or other Guangdong port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Guangdong, China	Brand Name:	BAOKEZHEN	Model Number:	SC706-3MRQ piano switch
Protection Level:	IP20	Max. Current:	1A-3A	Max. Voltage:	125V~250VAC

Product Description

SC706-3MRQ cooker hood piano switch range hood piano switch ,5-position piano switch

P/N	SC706-3MRQ piano switch
Current & Voltage	1A 125VAC T85/55 1E4 1A 125/250VAC
Life	6E3 / 5E4
Materials	Housing-PA Terminals-copper Alloy, Contacts-Ag / AgcdO
Contact gap	more than 3mm
Contact resistance	20 mΩ or less than 20 mΩ
Insulation resistance	more than 100 mΩ
High voltage resistance	1500VAC
Resistance to tracking	PTI 175
Protection type	IP20
Ambient temperature	0℃,+85℃
Flammability	UL94V-0
Heat and fire temperature	850℃
Temperature rise at the terminals (according to electrical life endurance)	Max 30K ( UL1054) Max 55K ( EN61058-1)
Approvals	UL & SEMKO
These switches are suitable for appliances of protection class II, such as cooker hood, range hood and so on. For more switches, pls refer to .
