digital tv single channel signal converter HDMI to RF encoder modulator

Name: digital tv single channel signal converter HDMI to RF encoder modulator
Brand: Sighton
Availability: InStock

FOB Price

USD $300 - $600 / Set

1 Set(Min.Order)

Supply Ability 2500 Set / Sets per Month
Port Chengdu Shenzhen Shanghai Ningbo
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Sichuan, China

Brand Name:

Sighton

Model Number:

STHM-3380

Product Description

digital tv single channel HDMI to RF encoder modulator

Product Description

Outline

STHM-3380 series encoder & modulator is consumer electronics which allows audio/video signal input in TV distributions with applications in home entertainment, surveillance control, hotel Digital Signage, shops etc.
It is an all-in-one device integrating MPEG-4 AVC/H.264 encoding and modulating to convert audio/video signals into DVB-T/DVB-C/DTMB/ATSC/ISDB-T RF out.

The signals source could be from satellite receivers, closed-circuit television cameras, Blue-ray players, and antenna etc. its output signal is to be received by a DVB-T/DVB-C/DTMB/ATSC/ISDB-T standard TV, DVB-T/DVB-C/DTMB/ATSC/ISDB-T STB etc

Except for h.264 hdmi/cvbs/Ypbpr to rf modulator home version, there are mini mpeg2 sd cvbs/YPBPR to modulator;1U standard encoder modulator,support multiple inputs, such as HDMI/SDI/YPbPr/CVBS/VGA,Pls contact us to fetch more.

What is the Specification of our single channel hdmi encoder modulator?

HDMI	Video	Encoding	MPEG-4 AVC/H.264
		Interface	HDMI*1
		Resolution	19201080_60P,19201080_50P;19201080_60i, 19201080_50i; 1280720_60p, 1280720_50P
		Bit rate	0.500~19.500 Mbps
	Audio	Encoding	MPEG1 Layer II, (MPEG2-AAC, MPEG4-AAC available)
		Interface	HDMI
		Sample rate	48KHz
		Bit rate	64, 96,128, 192, 256, 320, 384kbps
YPbPr/ CVBS/S-Video(with an adapter to VGA)	Video	Encoding	MPEG-4 AVC/H.264
		Interface	CVBS 1, YPbPr1,S-Video*1
		Resolution	CVBS&S-Video: 720x576_50i (PAL); 720x480_60i (NTSC) YPbPr: 19201080_60i, 19201080_50i; 1280720_60p, 1280720_50P
		Bit rate	0.500~19.500 Mbps
	Audio	Encoding	MPEG1 Layer II, (MPEG2-AAC, MPEG4-AAC available )
		Interface	1*Stereo /mono
		Sample rate	48KHz
		Bit rate	64, 96,128, 192, 256, 320, 384kbps

DVB-T Modulator Section

Standard	DVB-T COFDM
Bandwidth	6M, 7M, 8M
Constellation	QPSK, 16QAM, 64QAM,
Code rate	1/2, 2/3, 3/4, 5/6, 7/8.
Guard Interval	1/32, 1/16, 1/8, 1/4
Transmission Mode:	2K, 8K
MER	≥42dB
RF frequency	30~960MHz, 1KHz step
RF output level	-16~ -36 dBm (71~91 dbµV), 0.1db step

ISDB-T Modulator Section

Standard	ARIB STD-B31
Guard Interval	1/4, 1/8, 1/16, 1/32
Transmission mode	2K,4K,8K
Bandwidth	6M
MER	≥42db
RF frequency	30~960MHz, 1KHZ step
RF output level	-16~-36dbm (71~91dbµV), 0.1db step
Constellation	DQPSK,QPSK,16QAM,64QAM

System Section

Management	Local control: LCD + control buttons
Language	English
LCN Insertion	yes
Power supply	DC 12V
Dimensions	15311050mm
Weight	< 1kg
Operation temperature	0~45°C

STHM-3380 not only supports DVB-T/ISDB-T modulator, but also supports DVB-C/ATSC-T/DMBT.

Sketch Map

What is the System Applications of our single channel hdmi modulator?

Connection

USB Application

Application Examples

More Similar Products And Click It




Click For More:http://sighton.en.

Packaging & Shipping

Trade,Packing & Shipping

Trade Process

Shipping 1.Door-to-Door; DHL/FedEx/UPS/TNT for samples, which one is convenient for you? 2.By Air or by Sea for batch goods;Airport/Port receiving; 3.Delivery Time: 5-7 days for samples; 5-25 days for batch goods.

Payment Terms

1.MOQ:1pcs

2.Warranty:one year

3.Payment:T/T,Western Union,PayPal;

4.Package Informations:1 pcs per carton with foam, the volume of the carton is 153mm×110mm×50mm
