rf signal converter dvb-s s2 dvb-c to iptv gateway

Name: rf signal converter dvb-s s2 dvb-c to iptv gateway
Brand: Sighton
Availability: InStock

FOB Price

USD $1 - $3,000 / Set

1 Set(Min.Order)

Supply Ability 2500 Set / Sets per Month
Port Chengdu Shenzhen Shanghai Ningbo
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Sichuan, China

Brand Name:

Sighton

Model Number:

STGI-7100(DVB-S/S2/C)

Product Description

rf signal converter dvb-s s2 dvb-c to iptv gateway

Product Description

Outline

DVB-S/S2/C to IP Gateway is a head-end interface conversion device which is used for DVB, ASI and Ethernet. It supports SPTSx32 output.

It is also integrated with demodulation and gateway function, which can demodulate the signal from 10 tuners (ASI) into TS. After multiplexing the TS, then packet the TS into IP package and output the IP package through different IP address and ports. It supports IP output (UDP protocol).

Except for Tuner Input(DVB-S/DVB-S2 /DVB-T/DVB-C/ISDB-T/ASI optional) to IP Gateway model, there are HD/SD Encoder,IRD, Modulator etc.Pls contact us to fetch more.

What is the Features of our iptv gateway ?

Integrated with demodulation and gateway function

Support 10 channels tuner (ASI) input and SPTSx32 output.

Support MPEG-2 and MPEG-4 TS to IP one way conversion

1 GE output(support parallel 1 Gbps data output channel)

Support maximum 8 tuner to IP converting channel, the maximum output bit-rate is 800Mbps

Support IP output, UDP protocol, unicast and multicast

Support LCD display and keyboard

Support SNMP operation

What is the Specification of our iptv gateway ?

Input	10 tuner input(DVB-S/DVB-S2/DVB-C optional) DVB-C: 47 MHz~860 MHz, 16/32/64/128/256 QAM DVB-S: 950 MHz~2150 MHz, symbol rate: 2~45Mbauds DVB-S2: 950 MHz~2150 MHz, symbol rate: QPSK 1~45Mbauds, 8PSK 2~30Mbauds DVB-T: 146MHz ~862 MHz, 6/7/8 M bandwidth DVB-T2: 44MHz ~999 MHz, 6/7/8 M bandwidth ISDB-T: 153 MHz ~862 MHz, 6/7/8M bandwidth
	8 ASI input
Output	1 GE output, UDP protocol, unicast and Multicast
Transmission Bit-rate		Maximum total bit-rate is 800Mbps
General	Dimension(WxLxH)	482mm×410mm×44mm
	Weight	3.6kg
	Temperature	0~45℃(working ),-20~80℃(storage)
	Power supply	100~240VAC,50/60Hz
	consumption	20W

What is the Applications of our iptv gateway ?

What is the System Applications of our iptv gateway ?

Tuner Input(DVB-S/DVB-S2 /DVB-T/DVB-C/ISDB-T/ASI optional) to IP Gateway is widely used for IPTV system.

Network Management System

Tuner (DVB-S S2) Setting

Select Programs
IP Output Address Setting

More Similar products And Click It




Click For More:http://sighton.en.china.cn

Packaging & Shipping

Trade,Packing & Shipping

Trade Process

Shipping 1.Door-to-Door; DHL/FedEx/UPS/TNT for samples, which one is convenient for you? 2.By Air or by Sea for batch goods;Airport/Port receiving; 3.Delivery Time: 5-7 days for samples; 5-25 days for batch goods.

Payment Terms

1.MOQ:1pcs

2.Warranty:one year

3.Payment:T/T,Western Union,PayPal;

4.Package Informations:1 pcs per carton with foam, the volume of the carton is 440mm×410mm×44.5mm

Company Information

Company View

Chengdu Sighton Technology Co., LTD. is more than five years manufacturer, specialized in digital TV head-end system.The company is a high-tech enterprise which concentrates on the research, manufacturing, sale and service of DVB products. Sighton is building up both domestic and overseas markets while making a good contribution to the CATV industry. Sighton's products including: Encoder, Encoder modulator, QAM modulator, QPSK modulator, DVB-S2 modulator, DVB-T modulaotr, multiplexer and Satellite Receiver...For the system, we can offer the total solution of DVB-C/T/T2/ from headend to user end with the way of cable, MMDS,especially concentrate on IPTV.And our projects relate to different areas, such as city or village coverage, hotel, hospital, university, casino etc.
