fruit dryer/vegetables dryer machine/dehydrated vegetables drying machine

Specifications

fruit dryer/vegetables dryer machine/dehydrated vegetables drying machine
energy saving
safe and clean
stainless steel

fruit dryer/vegetables dryer machine/dehydrated vegetables drying machine





Structural features:

Heat sensitive materials can be dried,dehydrated,condensed quickly under the normal temperature condition.Their dehydrated termperature is controlled under 40 centigrade.It makes features of infared measurement of temperature,digital timin,power adjustable,intelligent control,easy operation,even heating,and enrgy sving 50% in power consumption compared with general equiopments.Besides, it is also used for the drying,dehydration,and condensed treatment of many oxidizable materials.Materials can be processed three-dimensional rotation ad area of spreading materials is bi.There are different gades of equipments to be selected.

Functional Characteristics:
(1) It characterizes intelligent control, power linearity adjustable and controllable temperature. It is a upgrade from general industry microwave oven.
(2) Our company is the first to introduce PLC controlling into microwave produces among competitors in the same trades. Via many times of technical upgrade, its controlling method and functions have taken the lead among like products of domestic industry.
(3) High-tension transformer adopts secondary cooling system, ensuring that the machine can continuously work for 24 hours.



Structural Features:
This series cabinet microwave equipment is composed of control unit, microwave heating cabinet, three-dimensional rotating basket, rotation system, and electrical system. Its exterior is neat and beautiful.



High efficiency: compared with general drying technologies,it can increase work effciency at least four times above.



Even heating: As micorwave heating heats up the inside and outside of materials at one time.Temperature difference between the inside and outside of materials is tiny,Thus,there is no question of apperaring heating variance of inside and outside which general heating will happen.Drying quality is greatly improved.



Easy to control:  it is convenient for continuous production,and it realizes automatization.Based on its characteristics of quick arrangement of microwave power and no inertia, it is easy to instant

control,as well as arrangement and determination of process parameters.



Small size: There is monitour installed in the interior,which can observe all courses of drying.





ItemUnit	HWZ-BC		HWZ-BC	HWZ-BC		HWZ-BC			HWZ-25B/30B
Microwave Power	5		10	15		20			25-30
Microwave Frequency	2450		2450	2450		2450			2450
Supply Voltage	380±10%		380±10%	380±10%		380±10%			380±10%
Area ofspreading materials	0.75		0.75	2.25		2.25			3.4
Sterilization Capability	10 — 20
Dehydration Spssd kg/ kw .h	0.8—0.2
Dehydration Temperature °C	30—100
External dimension (L*W*H)	1290*1190*1880	1580*1190*1880			1780*2000*2140		1780*2000*2140	1880*2400*2420
