Home > Products > Water Source Heat pump > 2014 Hot Selling Water Heat Pump (water to air heat pump)

2014 Hot Selling Water Heat Pump (water to air heat pump)

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port shenzhen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Water Source Heat Pump	Installation	Wall Mounted
Storage / Tankless	Other, air to water	Housing Material	Stainless Steel
Use	Other, Industrial / commercial building	Certification	CB, CE, CSA, EMC, EMF, GS, LFGB, Other, UL, UR, CB, CE, CSA, EMC, EMF, GS, LFGB, RoHS, UL, UR
Place of Origin	Guangdong, China	Brand Name	hICOO
Model Number	H-WP30B

Product Description

Water Heat Pump

Features:

1. High efficiency, energy saving, investment saving
The water cooled packaged heat pump has higher efficiency than air cooled heat pump. If the system needs to supply cooling capacity and heating capacity at the same time, the unit can realize internal energy balance, reduce operation time of cooling tower and heating equipments to save energy. Meanwhile, comparing with traditional central air conditioners, this unit does not need special machine room or big air duct.

2. Easy to install, flexible application
Simple design and installation, less control devices, easy to configure water pipe work, short designing period. Meanwhile, user can select cooling or heating according to different application conditions, or partial cooling with partial heating.

3. Separate measuring
It can connect to user’s independent electric meter, convenient for separate calculation of electric charges, help to avoid conflict.

4. Introducing fresh air to improve air quality
The system can introduce fresh air, exempt annoyance of air-condition disease.

Application range

Widely applied to office buildings, apartments, hotels, banks, schools and gymnasiums etc.

Finished production:

Technical Data:

Water Source Heat Pump Parameter
Model			H-WP30B	H-WP36B	H-WP42B	H-WP60B	H-WP75B	H-WP95B	H-WP125B
Cooling Capacity		kW	3.0	3.6	4.1	6.1	7.8	9.2	13.0
Heating Capacity		kW	3.1	3.7	4.2	6.3	8.0	9.3	13.3
Rated Input Power	Cooling	kW	0.8	1.0	1.1	1.7	2.0	2.7	3.6
Rated Input Power	Heating	kW	0.9	1.1	1.2	1.8	2.1	2.8	3.7
Rated Input Current	Cooling	A	3.6	4.6	5.1	8.1	9.6	11.5	6.1
Rated Input Current	Heating	A	3.9	5.0	5.5	8.6	10.0	11.7	6.3
Power Supply			220V~/50Hz/1Ph						380V~/50Hz/3Ph
Compressor	Type		Rotary						Scroll
Compressor	Quantity		1	1	1	1	1	1	1
Refrigerant			R22(R410A)
Refrigerant Charge		kg	1.2	1.4	1.6	2.0	2.2	2.7	3.0
Protection			High/low pressure protection, over-heat protection, over-current protection, water break protection
Air Flow Volume		m³/h	550	600	850	1300	1600	1800	2400
Fan Power		W	25	30	40	50	70	90	120
Static Pressure		Pa	30	30	30	30	30	30	40
Cooling Water Flow		m³/h	0.60	0.75	0.80	1.20	1.80	2.15	2.67
Cooling Water Connecting Pipe			DN20	DN20	DN20	DN25	DN25	DN32	DN32
Water Resistance		kPa	6.0	8.0	10.0	12.0	14.0	23.0	25.0
Noise		dB(A)	38	39	41	43	45	47	48
Net Dimension(LxWxH)		mm	1060×580×410	1060×580×410	1060×580×410	1144×645×480	1144×645×480	1144×645×480	1350×645×550
Net Weight		kg	58	65	72	76	80	95	105
Packing Dimension(LxWxH)		mm	1180×600×480	1180×600×480	1180×600×480	1260×665×550	1260×665×550	1260×665×550	1480×665×620
Gross Weight		kg	62	69	76	80	85	100	110
Note: 1) Nominal cooling conditions: indoor dry bulb: 27°C, indoor wet bulb: 19°C, cooling water inlet: 30°C, cooling water outlet: 35°C 2) Nominal heating conditions: indoor dry bulb: 20°C, indoor wet bulb: 15°C, cooling water inlet: 20°C, cooling water outlet: 15°C. 3) Applicable temperature range: 21-30°C 4) Manufacturer keeps the right to change the above parameter without prior notice

About us

HICOOL REFRIGERATION INDUSTRY(HUIZHOU) CO., LTD is one of the most professional factories specialized in designing, manufacturing and exporting Commercial / Central air conditioning equipment, located in Huizhou City of Pearl River Delta , with occupation area of 25,000 square meters.

Since established in 2008, HICOOL has been insisting on developing new technologies and new products based on requirements of different customers from different countries and regions all around the word, under the guidance of Safe &Reliable, Efficient & Environmental, Creative & Technological, Precise & Improving , to offer products with reliable quality, elegant design and high efficiency. Our factory owns advanced producing lines and equipment, as well as famous testing systems, under the control of international advanced management system ISO9001. And, we've also obtained the certification of CE, CB, etc, for our main products.

HICOOL can offer complete series of commercial / central air conditioner products, including High / Low Static Duct Type unit, Rooftop Packaged unit, Air-cooled Split Type unit, Small / Modular Air-cooled Chiller (H.R. optional), Swimming Pool Heat Pump unit, Air Source Heat Pump (H.R. optional), Ground Source Heat Pump unit, Air-cooled Scroll / Screw Chiller, Water-cooled Scroll / Screw Chiller, Air Handing Unit, Fan Coils, VRV system, Cassette type, etc. These products are well approved in both domestic and overseas market, and we're exporting the products to many countries and regions in East Europe, Middle East, South Africa, Oceania, South America, etc.

HICOOL has been focusing on offering the best products together and most satisfying services to our customers since the very beginning, and our services system runs through the whole process of businesses, including product R&D, product design, manufacture, before and after sale service. We're also aiming to improve our product and services continuously through the latest and most reliable technology in refrigeration field, based on the requirements of different customers.

High Quality Creates Cool Life . We believe that HICOOL will create more values for customers and society, through our competitive products and full-round services, as well as our sincerity in cooperation with different customers, and you.
