Specifications
Timing Conveyor Belt For Hot Sale1.LOW noises,NO slippage
2.HIGH transmission power
3.Wear Out Resistance
Specifications
High quality raw material and the advanced craft unify enable the product to have the high strength and the good flexibility.
Timing Belt
Specifications:
1. It combine respective advantage of gear transmission,chain transmission and belt transmission.
2. Solve the problem such as low transmission efficency,lubbrication oil required under the status of high speed when using the chain,distance limit between the drive part and the slave drive part when using the gear.Fiber glass as tensile composision,no elongation of rubber belt.excelent hear-resistance,oil-proof,wearing resistance.
3. We also accept OEM design according to customers requirement.
4. We can accept special specification types.
Features:
1.Low noises,No slippage
2.High transmission power
3.Wear Out Resistance
Type:
| Type | Pitch Pb (mm) | Tooth height ht(mm) | Belt thickness hs(mm) | Angleβ° |
| MXL | 2.032 | 0.51 | 1.14 | 40 |
| XL | 5.08 | 1.27 | 2.3 | 50 |
| L | 9.525 | 1.91 | 3.6 | 40 |
| H | 12.7 | 2.29 | 4.3 | 40 |
| XH | 22.225 | 6.35 | 11.2 | 40 |
| XXH | 31.75 | 9.53 | 15.7 | 40 |
| T2.5 | 2.5 | 0.7 | 1.3 | 40 |
| T5 | 5 | 1.2 | 2.2 | 40 |
| T10 | 10 | 2.5 | 4.5 | 40 |
| T20 | 20 | 5 | 8 | 40 |
| AT5 | 5 | 1.2 | 2.7 | 50 |
| AT10 | 10 | 2.5 | 5 | 50 |
| AT20 | 20 | 5 | 8 | 50 |
Arc ToothType | Pitch pb(mm) | Tooth height ht(mm) | Belt thickness hs(mm) |
| 2M | 2 | 0.75 | 1.36 |
| 3M | 3 | 1.17 | 2.4 |
| 5M | 5 | 2.06 | 3.8 |
| 8M | 8 | 3.36 | 6 |
| 14M | 14 | 6.02 | 10 |
| 20M | 20 | 8.4 | 13.2 |
| S2M | 2 | 0.76 | 1.36 |
| S3M | 3 | 1.14 | 2.2 |
| S4.5M | 4.5 | 1.71 | 2.81 |
| S5M | 5 | 1.91 | 3.4 |
| S8M | 8 | 3.05 | 5.3 |
| S14M | 14 | 5.3 | 10.2 |
| RP2M | 2 | 0.76 | 1.36 |
| RP3M | 3 | 1.15 | 1.9 |
| RP5M | 5 | 1.95 | 3.5 |
| RP8M | 8 | 3.2 | 5.5 |
| RP14M | 14 | 6 | 10 |
We are factory:
Our factory also produces and sells:
Polyester Conveyor Belt | Cotton Conveyor Belt |
Heat Resistant Conveyor Belt | Oil Resistant Conveyor Belt |
Cold Resistant Conveyor Belt | Chemical Resistant Conveyor Belt |
Chevron Conveyor Belt | PVC/PVG Solid Woven Belt |
Endless Belt | V-Belts |
