Home > Products > thread Steel Cross Type Bit > Thread Steel Cross Type Button Bit For Rock drilling Bit
Thread Steel Cross Type Button Bit For Rock drilling Bit
- 30000 Piece / Pieces per Month
- China Port
- L/C D/P D/A Credit Card PayPal
You May Like
-
H25 H-Thread Steel Cross Type Button Bit For Rock Drilling Tools
-
R25 Thread Cross Type Rock Button Bit For Drilling
-
R28 Thread Cross Type Rock Mining Drill Button Bit
-
R32 Thread Cross Type Rock Button Bit
-
T38 X-type Bit Thread Cross Rock Button Bit
-
R38 X-Type bit Mining Tools Thread Cross Steel Type Bits
Product Details
| Place of Origin | Shandong, China | Brand Name | MIROC | |
| Model Number | CR35-H25 to CR76-H25 | Type | Other, H-thread Steel Cross Type Bit | |
| Material | Tungsten Carbide | Use | Other, Rock and Coal Mining Drilling |
Product Description
Our Company
KSQ Technologies (Beijing) Co. Ltd. is a diversified enterprise based in Beijing, China, offering a portfolio of products that help contribute to a better bottom line and increase workplace safety for the construction and mining industries. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations. Our operations are based on the unique expertise of our people and knowledge with customer processes.
Specifications
High grade tungsten carbide inserts
Bit bodies manufactured from high grade steel and processed using state-of-the-art
Descripetion
Cross type bit with steel inserts using H25 thread system.
It has a slow penetration rate but it produces a very straight drill hole.
• Steel inserts
• Widely used in dimensional stone industry, drifting and tunneling
Color: Green,Blue or Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: H25 H-thread Steel Cross Type Bit
Product Technical Reference
< High Performance 45mm 2" H25 Cross Bits Steel CNC Drill Bits
| Part Number | Product Code and Brief Description | Bit Diameter (mm) | Bit Diameter (inch) | Tip Size (W x H, mm) | Front Flushing drill holes | Side Flushing drill holes | Weight (kg) |
| 4148300324 | CR35-H25, H25 H-thread Cross Type Bit | 35 | 1 3/8 | 12 x 8 | 1 | 4 | 0.22 |
| 4148300325 | CR38-H25, H25 H-thread Cross Type Bit | 38 | 1 1/2 | 12 x 8 | 1 | 4 | 0.26 |
| 4148300326 | CR41-H25, H25 H-thread Cross Type Bit | 41 | 1 3/5 | 12 x 8 | 1 | 4 | 0.3 |
| 4148300327 | CR45-H25, H25 H-thread Cross Type Bit | 45 | 1 7/9 | 14 x 8 | 1 | 4 | 0.38 |
| 4148300328 | CR48-H25, H25 H-thread Cross Type Bit | 48 | 1 8/9 | 14 x 8 | 1 | 4 | 0.42 |
| 4148300329 | CR51-H25, H25 H-thread Cross Type Bit | 51 | 2 | 14 x 8 | 1 | 4 | 0.5 |
| 4148300330 | CR54-H25, H25 H-thread Cross Type Bit | 54 | 2 1/8 | 14 x 8 | 1 | 4 | 0.5 |
| 4148300331 | CR57-H25, H25 H-thread Cross Type Bit | 57 | 2 1/4 | 16 x 10 | 1 | 4 | 0.61 |
| 4148300332 | CR64-H25, H25 H-thread Cross Type Bit | 64 | 2 1/2 | 16 x 10 | 1 | 4 | 0.71 |
| 4148300333 | CR70-H25, H25 H-thread Cross Type Bit | 70 | 2 3/4 | 16 x 10 | 1 | 4 | 0.88 |
| 4148300334 | CR76-H25, H25 H-thread Cross Type Bit | 76 | 3 | 20 x 12 | 1 | 4 | 1.25 |
Applications
• Dimensional Stone Industry
• Underground Mining
• Tunneling
Packaging:Carton or Wooden Box
KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:
- Hazardous environment
- Acts, regulations, and other government guidelines that has to be followed
- Significant differences in the way people work, mostly due o physical constraints
- Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.
KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations.
