New sinotruck howo 6x4 The sky Spraying water fire engine truck factory price
The overall description of our squirt water tower fire truck series
Our company are professional manufacturer in fire fighting truck area, guarantee all goods Brand-New and China-Origined.Compared with any other manufacturers, we can provide various configuration trucks with best prices and best quality.
1. Type: water tank fire fighting truck, foam tank fire fighting truck, dry powder tank fire fighting truck, emergency resue fire fighting truck, lift-up fire fighting truck and etc ;
2. Drive model: 4*2, 4*4, 6*4, 6*6, 8*4;
3. Capacity: 2-15CBM;
4. Tank Material: cabon steel plate, stainless steel plate, etc;
5. Cab:Single row or double rows, Right/Left hand drive, with A/C;
6. Fire pumps: middle pressure pump, low pressure pump, high pressure pump, ordinary pressure pump, etc;
7. Other descriptions: Equipment box with 5-9 curtain doors, truck body with stoving varnish, 1100-1600mm alarm lamp, can be equipped with all kinds of fire fighting equipment.
New sinotruck howo 6x4 The sky Spraying water fire engine truck factory price
1. We are the manufacturer
2. OEM is OK.
3. ISO certificate
Product Photos
the detailed techinical parameters of squirt water tower fire truck
| New sinotruck howo 6x4 The sky Spraying water fire engine truck factory price | ||||
| The totalmass(kg) | 24300 | Curb Weight(kg) | 16300 | |
| Rated the quality of(kg) | 7850 | Chassis Model | ZZ1256M4646C | |
| Approach / departure angle(°) | 15/13 | Front overhang / rear overhang | 1560/2320 | |
| Dimensions(mm) | 9835X2490X3900 | Compartment dimension(mm) | ||
| Number of axes | 3 | Maximum speed | 85 | |
| Tire Specifications | 11.00-20,12.00R20 | Number of tires | 10 | |
| Front track | 1939,1958 | Rear track | 1800,1830 | |
| Wheelbase | 4600 | Axle load | 6300/18000 | |
| Number of spring | 9/12 10/12 | Type of fuel | Diesel | |
| Emission Standards | Euro III | |||
| Engine parameters | ||||
| Engine Model | WD615.92 | Engine Manufacturer | Sinotruk | |
| Engine Displacement | 9726 | Engine power | 213 | |
| Chassis Description | 1,Sinotruck 6x4 chassis,flat and crew cab , left/right hand drive ,A/C; 2,300HP,6 cylinder diesel engine , emission standard Euro III/IV, 12 shift gearbox ; 3,10 ton double rear axle , gas brake , power steering | |||
| Modified Description | 1,Fire fighting truck:fire-extinguishing water tanker,fire-extinguishing foam tanker,water-foam fire fighting truck, emergency rescue fire truck and ect. 2,Equipped with fire pump,PTO,storage compartment,long-line lights and fire monitor. | |||
| Composition | Basic composition:chassis,fire pump,PTO,storage compartment,long-line lights and fire monitor,fire fighting tools and ect. | |||
| Application | Fire fighting truck is specially used for fire fighting vehicles or other emergency rescue purposes. This truck can be devided into pump truck(water supple vehicle sprinkling water or fire), aerial(high save) and other special vehicles by its function. | |||
| Product advantage | reasonable price,multiple functions,easy operation | |||
Accessory Diagram
