Home > Products > Solar Framing machine > Keyland Solar panel frame machine with automatic
Keyland Solar panel frame machine with automatic
- 5000 Set / Sets per Month
- Shanghai/Be appointed
- T/T L/C D/P D/A
You May Like
-
Solar Panel Framing Machine For Frame Solar Moduel
-
Low Price Solar Panel Frame Machine in Solar Production line
-
Solar Module Packing Framing Machine for Solar Panel Frame
-
Hydraulic Pressure Solar Module Frame Machines Cost
-
Solar Panel Framing Machinery Price for Solar Frame Machines
-
Solar Panel Frame Machines For Framing Solar Panels System
Product Details
Place of Origin | Jiangsu, China | Brand Name | Keyland laser /OEM | |
Model Number | KL-ZKJ | Usage | Other, Solar Module Framing Machine |
International transport plywood package
Product Description
Keyland solar panel frame machine automatic
Solar module framing machine is framing up various materials in the automatic solar module production line, like silicone rubber and gummed strip.
(Model:KL-ZKJ) without ram
| Compound-Framing-machine -Aluminum alloy materials By Air cylinder, and steel structure Universal wheel makes operation Convenient Two-way fixed end and two-way activity Framing accuracy:+1 Scope of framing:0.18*0.18m 2.0*2.0m Can be designed according to your request. | |
(Model:KL-M1) with Ram Compound-Framing-machine -Aluminum alloy materials By Air cylinder, cylinder, direct rail and steel structure
| Model No | KL-m1 |
Max. Framed Dimensions | 2000*1200*(35~30)mm | |
Min. Framed Dimensions | 200*180*(35~30)mm | |
Framing precision | 1mm | |
Diagonal size of the difference | ±1.5mm | |
Square angular deviation | ±0.5 | |
Driving force of frame | Pneumatic, hydraulic | |
Working Pressure | 0.4Mpa~0.7Mpa | |
Size of mc | 2.9*1.9*0.97m | |
Hydraulic Pressure | 1.0 Mpa~15Mpa | |
Operation | manual | |
Weight | 1200KG |
Perform Accuracy: | Difference between the opposite sides within ±1mm |
Difference between the diagonal sides within 1.5mm; | |
Difference between the four angles within ±0.5degree; |
* Can be designed according to clients' request.
Also other solar panel making line's equipments can be supplied by keyland:
Our production line include:
1.Solar module tester
2.Semi-automatic laminator
.Solar cell tester
4.Extrude framing
5.El Tester
6.Single welding heating plate
7.String welding hearing plate
8.String welding hearing plate
9.String welding cell cassette
10.Auxiliary working table
11.soldering station
12.Laying up station
13.Ready material carrier
14.Ready pressing table
15.Multi-angle observations holder
16.EVA, TPT cutting station
17.Cell string shelf
18.Cell sorting table
19.Trimming working table
20.Thermostatic electric iron
Contact Lucia Lv ,
Exact details with good price will be sent.
Hope to cooperate with you.
Company Profile

Jiangsu Keyland Laser technology Co., Ltd. (Keyland laser) is a high-tech enterprise with 20 years' experience in the R&D, production and sales of laser equipment. Our company has annual production capacity of 6,000 sets of equipment. The company locates in China Optical Valley, with import and export rights. We are committed to providing the customers with comprehensive and integrated laser processing and application solutions of solar energy equipment.
The main products of Keyland Laser are solar photovoltaic equipment, laser scribing-cell machine, laser scribing-film machine, laser marking machine, laser cutting machine, laser engraving machine, laser engraving and cutting machine, laser cutting flat bed and other 10 series. 100 section models are widely used in solar energy, electronics, clothing, leather, advertising, arts and crafts, automotive, motorcycle, hardware, measuring tools, cutting tools, plumbing ware, medical equipment, eyeglasses, glass craft, food, pharmaceutical, printing and packaging, furniture, decoration and etc., about 1,000 kinds of industries and fields.
Keyland Laser wins the praise of domestic and overseas customers in each industry by right of the high-quality products and professional services. We have got a leading position in the domestic sales, even over more than 40 countries and regions. Our products have been sold to the United States, Germany, France, Poland, Italy, Russia, Japan, Korea, India, Iran, Singapore, Malaysia, Brazil, Sweden, Saudi Arabia, Australia, Syria and other countries and regions.
Keyland Laser takes the lead in laser equipment manufacturing technology. We have over 10 years of experience in laser design & services, from software development to hardware design. System testing equipment and technical service are all completed by the professional technology personnel.
Keyland Laser has set many bases of research in Beijing, Shanghai, Guangzhou and Wuhan, and also has cooperated with the domestic & foreign research institutions and colleges closely. We have 65 national patent applications and core technology achievement in this field, with international leading level.
Keyland Laser is the laser expert of industrial application and your reliable business partner.no matter what industry you are engaged in, our products are always suitable for you.
