Side Drive Belt Carton Sealer Carton sealing machine

Automatic H Type Carton Sealing Line (CS5050A-HL)

Automatic H Type Carton Sealing Line is a high standards of carton packaging equipments, With advanced pneumatic adjusting system and belt driving system, Using for sealing up-bottom, corner and side of cartons automatically; It can seal different size of cartons at one time without stop, It is used widely for packing all sorts of productions with papery boxboards.
Application(Automatic Carton Sealing Line):
It applies to packing all sorts of productions with papery boxboards.
Technical Characters of Automatic Carton Sealing Line:
1. It can adjust width and height size of the machine to adapt to a variety sizes of cartons automatically.
2. Imported pneumatic and electric components ensure trouble-free operation for a long time.
3. Advanced belt drive system, High speed and smoothly.
4. Install large casters for easy mobility.
5. Easy operation and simple maintenance.
6. Automatic alarm and closing down system when faults occur.
Technical Specification(Automatic Carton Sealing Line):
Model:CS5050A-HL
Voltage:220V/50Hz or 380V/50 Hz
Power:720W
Packing Speed:300-360 cartons/hour
Adhesive Tape Width:48-75mm
Table Height:600± 50mm
Carton Length:320-500mm
Carton Width:200-500mm
Carton Height:180-500mm
Air Pressure(MPa):0.6-0.8Mpa
Weight:720kg
Machine Size:2100× 2900× 1580mm

CS5050A Motech Side Drive Belt Carton Sealer

Semi-Automatic Carton Sealer is a kind of carton sealing equipments, with advanced up-bottom belt driving system, Using for sealing UPS and bottoms of cartons automatically; It is used widely for packing all sorts of productions with papery cartons.
Application(Semi-auto Case Sealer):
It applies to packing all sorts of productions with papery boxboards.
Technical Characters of Semi-auto Case Sealer:
1. It can adjust width and height size of the machine to adapt to a variety sizes of cartons by hand.
2. Imported electric components ensure trouble-free operation for a long time.
3. Up-bottom sides of the belt driven, High speed and smoothly.
4. Install large casters for easy mobility.
5. Easy operation and simple maintenance.
Technical Specification(Semi-auto Case Sealer):
Model:CS5050A
Voltage:220V/50Hz or 110V/60Hz
Power:300W
Packing Speed:1200 Carton per hour
Adhesive Tape Width:48-60mm
Min. Carton Length:150mm
Carton Width:150-500mm
Carton Height:150-500mm
Weight:120Kg
Machine Size:1720× 950× 1550mm
Packing Size: 980× 850× 1250mm
