HTB19 AC motor for top drive

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Tianjin Shanghai
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Shandong, China	Brand Name:	SINOTAI	Model Number:	HTB19
Type:	Other, AC motor for top drive	Machine Type:	Drilling Equipment	Certification:	API
Material:	High Manganese Steel	Processing Type:	Casting	Use:	Well Drilling

Packaging Details

Standard export package or as consumer's need

Product Description

Specifications

1.Great torque
2.Mall size, light weight
3.High efficiency
4.Maintenance-free
5.High reliability

HTB19 AC motor for top drive

[ Offshore Drilling Module - Component ]

Product Explanation:This engine is a three-phase squirrel-cage induction motor researched to support the DQ70BZ direct& top drive device, which is used as the driving engine of direct& top device.

The engine is designed in accordance with the increased safety explosion-proof requirements , the main features are: low speed, great torque, wide range of speed control by constant power, strong overload capacity, low noise, high efficiency, maintenance-free, and high reliability.

Product types and specifications:

Power rating	288 kW
Voltage rating	575V
Current rating	399 A
Torque rating	25954 N·m
Rated revolution	106 r/min
Rated frequency	11 Hz
Power factor	0.79
efficiency	91%
Short time current	698A
Short-term torque	45404 N·m
Constant power Max speed	181 r/min
Maximum constant frequency	19 Hz
Insulation class	H
Connection mode	Y
Work characters	S1
Protection level	Main engineIP44,connecting boxIP55
Cooling method	Forced ventilation( with wind pressure testing switch)
Cooling draught fan	Explosion-proof type three-phase asynchronous motor5.5kW,380V,50Hz,Exd ⅡB T4
Heater	AC 220V,290W,ExeⅡT4
Weight	5030 kg
