Industrial Wave Shape Conveyor Belt

Industrial Wave Shape Conveyor Belt photo-1
US$ 5 - 60 MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
huadu
Model Number:
GB/T7984-2001
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name huadu
Model Number GB/T7984-2001

Specifications

Industrial wave shape conveyor belt
1.high bonding degree
2.splendid flexibility
3.bottom cover rubber:1.5-4.5mm

Industrial wave shape conveyor belt





industrial wave shape conveyor belt



The parameter relationship of the base belt width and flange height is as the following table(mm):
Bandwidth B of baseBlock high HHorizontal baffle high H1The wave bottom wide B1Effective bandwidth B2Empty wide B3Horizontal baffle form
30040352518035TC
60555012040
8075
40060555018060TC
8075
10090
50080755025075TC
10090
120110
6501009050350100TC
120110
16014075300
80012011050460120TC
16014075410
200180
100016014075550150TC
200180
240220
120016014075690180TC
200180
240220
300260100640
140020018075830210TC
240220
300260100780
400360



 industrial wave shape conveyor belt



 industrial wave shape conveyor belt
