0-90 Degree Angle Corrugated Sidewall Conveyor Belt

0-90 Degree Angle Corrugated Sidewall Conveyor Belt

Base Belt Structure:
Four parts: Top cover rubber; Bottom cover rubber;
Reinforced core; Cross rigid.
Thickness of top cover rubber: 3-6mm;
Thickness of bottom cover rubber: 1.5-4.5mm.
Belt core: Cotton, Nylon, EP or Steel Cord
The Width is the same as normal belt. The standard meets with GB/T7984-2001.


Cleat:
Cleat types: T, TS, C, TC and TCS
The cleat is made of enforced fabric, solid, anti-shock to avoid distortion.
"TS" and "TCS" cleat are normally used for abrasion condition
"T" and "TS" cleat are normally used up to 40 degree
"TC" and "TCS" are normally used from 40 degree to 90

(c) the level of :2-10
(d) plastic cover: Face :1.5-8 mm non-Face: 0 mm-4.5mm
