Two or Three Bolts Polished Rod Clamp

Name: Two or Three Bolts Polished Rod Clamp
Brand: SINOTAI
SKU: 119578477
Availability: InStock

Sinotai Petroleum Equipment Co., Ltd. Silver Verified Supplier

5Yrs

US$ 200 - 1,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

SINOTAI

Model Number:

Type WL

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name SINOTAI

Model Number Type WL

Type Other, Polished Rod Clamp

Machine Type Drilling Equipment

Certification API

Material High Manganese Steel

Processing Type Forging

Use Well Drilling

Specifications

1. API 11B
2. Long service life;
3. Competitive price;
4. Best service,good quality
5. Size: 7/8-1 1/2"

Polished Rod Clamp

This product is manufactured based on the technical requirements of petroleum and natural gas industry standards (SY/T5029) in China.

This standard is equivalent to International standard ISO 10428 and API Spec 11B

Technical Specifications:

Type	Nominal diameter for polished rod (inch)
	1-1/2 in		1-1/4 in		1-1/8 in		1 in		7/8 in
	Working Load	Weight (Kg)	Working Load	Weight (Kg)	Working Load	Weight (Kg)	Working Load	Weight (Kg)	Working Load	Weight (Kg)
WL 18200	178KN (18160 Kgf)	10.2	178KN (18160Kgf)	10.0
WL 16000			157KN (16020Kgf)	7.2	157KN (16020Kgf)	7.2	118KN (12040Kgf)	7.2
WL 12000					118KN (12040Kgf)	5.5	100KN (10200Kgf)	5.5	78.5KN (8010Kgf)	5.5
