Specifications
1.High efficiency energy recovery2.On-site operation
3.Thermal components and long service life
4.Easy maintenance
Single and double stage gas expander
Product Explanation:Gas expander is a kind of energy recovery turbon machinery blading. The working medium is the high temperature stack gas with definite pressure engendered from such technological process as oil refining, chemical industry, electric power or metallurgy industries. The working medium is expanded in the expander and shaft work is exported to drive other engines or electrical generator.
Product Features:
1.High efficiency energy recovery 2.A long time continuous operation 3.Thermal components and long service life 4.On-site operation, easy maintenance 5.The Product number of units up to 60% of world production, the domestic market share reached 90%.And the YL33000A-type gas turbine which created by us is one of the world's largest gas expander models |
Product types and specifications:
1.Output power: 2000-33000 KW 2.Section gas pressure:0.20-0.60MPa 3.Section gas temperature: 500-760°C 4.Gas flow: 300-6200 Nm /min 5.Speed: 370-8000 r/min 6.Working media: gas 7.Design standard: HG/T3650-1999 Specifications for gas expander |
