Specifications
ISO9001 CE certificationLifetime service
20 years' experience
Insulation Phenolic Panel Making Machine
Insulation Phenolic Panel Making Machine With CE
Product Introduction:
1 The equipment is accurate and durable.
2 The tape mechanism has a tension control device, enabling the overlay material evenly into the mould, to make sure the piece has a smooth surface.
3 The side block and adhesive tape recirculation device can guarantee the sealing of the piece and its demoulding.
4 The double-crawler laminating system is of pressure proof, and can achieve a continuously automatic production and limit the foaming material within the mould, ensuring a stable feature in product size.
5 The following conveying and cutting systems can work simultaneously to produce plates of any length.
Technical Parameters:
ITEM | UNIT | PARAMETER |
Effective length of laminating machine | mm | 18000--36000 |
Effective width of laminating machine | mm | 1200 |
Effective height of laminating machine
| mm | 20--100 |
Laminating machine temperature control range | °C | ≤80 |
Foaming casting machine flow | Kg/min | 6--25 |
Anti-pressure capability of laminating machine (25°C) | Mpa | 3 |
Anti-pressure capability of laminating machine (70°C)
| Mpa | 2.8 |
Suitable production thickness | mm | 20--100 |
Capacity | m³/24h | 200 |
Dimension L*W*H | Mm | (40000--60000)*3000*4000 |
Installed power | KVA | 45 |
Total weight | Tons | 40--72 |
Processing of the machine in plant:
Chain plate processing:
The heating treatment bring the chain plate a high strength, non-deformation and high resistance to the expansive force from high-density products.
Laser cutting and hole drilling processing provides the precise standard of the spare parts.
Frame processing:
CNC (Computer Numerical Control ) grinder guarantees the smooth surface of the frame.
Assembling:
Product samples of the machine:
Appearance of the machine:
Certification:
Plant overview:
Please be free to contact with us if you are interested.
