Specifications
1. high polish/zinc plated.HDGAISI304.AISI316,Carbon steel.
2. casting,forged
| ITEM NO | SIZE | D | G | H |
| mm | mm | mm | mm | |
| ZHT6899B-1 | 2.5x3 | 12 | 3 | 19 |
| ZHT6899B-2 | 3.5x4 | 13 | 4 | 21 |
| ZHT6899B-3 | 4x5 | 14 | 5 | 23 |
| ZHT6899B-4 | 5x6 | 16 | 6 | 25 |
| ZHT6899B-5 | 6x7 | 18 | 7 | 28 |
| ZHT6899B-6 | 7x8 | 20 | 8 | 32 |
| ZHT6899B-7 | 8x9 | 22 | 9 | 35 |
| ZHT6899B-8 | 9x10 | 24 | 10 | 38 |
| ZHT6899B-9 | 10x11 | 26 | 11 | 41 |
| ZHT6899B-10 | 11x12 | 28 | 12 | 45 |
| ZHT6899B-11 | 12x13 | 30 | 13 | 48 |
| ZHT6899B-12 | 13x14 | 32 | 14 | 51 |
| ZHT6899B-13 | 14x15 | 34 | 15 | 54 |
| ZHT6899B-14 | 15x16 | 36 | 16 | 58 |
| ZHT6899B-15 | 16x17 | 38 | 17 | 61 |
| ZHT6899B-16 | 16x18 | 40 | 18 | 64 |
| ZHT6899B-17 | 18x20 | 45 | 20 | 72 |
| ZHT6899B-18 | 20x22 | 50 | 22 | 80 |
| ZHT6899B-19 | 22x24 | 56 | 24 | 90 |
| ZHT6899B-20 | 24x26 | 62 | 26 | 99 |
| ZHT6899B-21 | 26x28 | 70 | 28 | 112 |
| ZHT6899B-22 | 28x30 | 75 | 30 | 120 |
| ZHT6899B-23 | 30x32 | 80 | 32 | 128 |
| ZHT6899B-24 | 32x34 | 95 | 34 | 152 |
| ZHT6899B-25 | 34x36 | 100 | 36 | 160 |
| ZHT6899B-26 | 36x38 | 110 | 38 | 176 |
| ZHT6899B-27 | 38x40 | 115 | 40 | 184 |
| ZHT6899B-28 | 40x42 | 120 | 42 | 192 |
| ZHT6899B-29 | 42x45 | 150 | 45 | 240 |
Type: European Type,DIN6988B,BS464
Surface:electro galanized,hot dipped galanized,self colour.
1. Thimble type:Eruopean type,Italian type,JIS Type,G411,US type G414,Tube type,Heavy duty,DIN type
2. Material: Stainless steel AISI 304,AISI 316,Carbon steel, Malleable steel etc.
3. Surface:pickle or electrolysis and polish,hot dipped galvanized,electro galvanized,phosphated and self-colored etc.
4. Arts and crafts:drop forged,cast,stamping,Die cast
5. Special specifications can also be produced according to drawing and sample.
6. Our web site is
