ccb led bulb

Specifications

led bulbs:
1--100Lm/W,PFC:above 0.95
2--Input voltage:90-277 Vac
3--Warranty:3 years
4--Certificate:CE,RoHS,FCC,PSE



Lampen led specifications:









Lampen led specifications:



Model		CCB-QP00701-41-01
Desc		7W Led bulb
Led Quantities		7*1W
Led		US CREE/OSRAM/Edison/Samsung
Illuminance		650Lm
Input Power		90 ~ 277Vac
Led Driver		PFC>0.95, Power Efficiency > 0.88
Color Tempeture		2800 - 7000K
CRI		75 - 85 Ra
Working Temp		-35 ~ 55 degree
Working Humidity		10% - 85%
Storage Temp		-40 ~ 80 degree
Life Span		>80,000hrs
Fixture Size		φ60*135mm
Available socket		E27/E26/E40/B22





Related lampen led test report:





5W lampen led specifications:



Model		CCB-QP00501-31-01
Desc		5W Led bulb
Led Quantities		5*1W
Led		US CREE/OSRAM/Edison/Samsung
Illuminance		490Lm
Input Power		90 ~ 277Vac
Led Driver		PFC>0.95, Power Efficiency > 0.88
Color Tempeture		2800 - 7000K
CRI		75 - 85 Ra
Working Temp		-35 ~ 55 degree
Working Humidity		10% - 85%
Storage Temp		-40 ~ 80 degree
Beam Angle		120
Life Span		>80,000hrs
Fixture Size		φ60*125mm
Available socket		E27/E26/E40/B22





Related lampen led test report:





12W lampen led specifications:



Model		CCB-QP01201-61-01
Desc		12W Led bulb
Led Quantities		12*1W
Led		US CREE/OSRAM/Edison/Samsung
Illuminance		1150Lm
Input Power		90 ~ 277Vac
Led Driver		PFC>0.95, Power Efficiency > 0.88
Color Tempeture		2800 - 7000K
CRI		75 - 85
Working Temp		-35 ~ 55 degree
Working Humidity		10% - 85%
Storage Temp		-40 ~ 80 degree
Beam Angle		120
Life Span		>80,000hrs
Fixture Size		φ75*145mm
Available socket		E27/E26/E40/B22





Related lampen led test report:





Some other lampen led models:

1. 3W,4W, 6W, 8W, 10W, 15W,etc.
2. Dimmable type or non-dimmable led bulb.
3.Remote controlled led bulb





Our lampen led advantage:

1- With high quality series led we make color tempeture more in same color;

2- By cooperating with EURO/USA power company, we make

    our driver more efficiency and long life;

3- With different test machines and processes we make the products

    are of 0 defective rate to arrive at your hand;

4- With care & heart we handle them like BABIES;

5- With 8 years experience in foreign market, we are sure to let you gain more;

6- With intensive online technical support, we will answer you question

    within 4 hours;







CCB lampen led main features:



1. High efficiency, save energy, Minimal maintenance cost
2. The light decay is very small (less than 1% after 2000hrs working hours)
3. Unique patented heat sinking design
4. CE and RoHS certified
5. Working temperature rising: less than 20°C
6. Led efficiency above 100Lm/W





About us:

     We are the professional Led manufacturer in China and has 8 years
Experience in R&D  produce many kinds of Led tube, led bulb,Led

downlight etc.We only pay attention to high quality led products.

All our products have passed CE,RoHs,FCC,PSE,UL certificates

and spread through USA,Canada,Germany,U.K.Japan,and Australia,etc.
