AC/DC digital power meter for LED production line testing Frequency power meter, power analyzer
Products Features:
1. Can test the AC signal, DC signal
2. Four windows LED display, voltage, current, power, power factor/frequency at the same time
3. All measurements are TRMS
4. Automatic range
5. Accuracy: 0.5
6. Not affected by external noise
7. Suitable for various electricity situation with 100-240V ac power supply
8. Its shell uses soft rubber material which is beautiful shatterproof and durable
9. Support data latching
10. Can set the upper and lower limit for alarm function
11. The product is suitable for uses in the production line test, such as lighting products, home appliances, electrical machine products, power products. etc.
Specification:
Connection | Single Phase |
Display | Four Windows display, Seven-segment digital tube |
Measuring items | Voltage-V, current-A, active power-W, power factor-PF, frequency-HZ |
Measuring form | True Root Mean Square(TRMS) |
Voltage Range DC | 75v/150V/300v/600v DC(Switch the range automatically Peak Voltage:700v DC Min test voltage:5v(Below 5v, can't be tested) |
Voltage Range AC | 75v/150V/300v/600v AC(Switch the range automatically Peak Voltage:700v AC Min test voltage:5v(Below 5v, can't be tested) |
Current Range DC | 0.5A/2A/8A/20A DC (Switch the range automatically) Peak Current:26A DC Min test current :10mA DC (Below 10mA, can't do tested) |
Current Range AC | 0.5A/2A/8A/20A AC (Switch the range automatically) Peak Current:26A AC Min test current :10mA AC (Below 10mA, can't do tested) |
Power Range(AC/DC) | 0.1W-9999W |
The frequency range | 45-400Hz Note: when it is DC signal, no frequency display |
Basic Accuracy | ±0.4% reading +0.1%range+1 digit |
Measuring Speed | Five times per second |
Input Impedance | ≥1MΩ(All voltage) |
Power Supply | 100~240V AC 50/60 Hz |
Volume and weight | 29cm(L)*22.5cm (W)*9.7cm(H), 1.8KG |
Attachment | Power line, fuses, specification |
Power factor Range(AC) | 0.001-1.000 Calculation method: Watt(W)/[voltage(V) current(A)]=Power Factor(PF) Note: when t is DC signal, power factor PF display 1.000 |
Areas of Application:
Power consumption test for household appliance;
