Aluminium Wire Rope Winch

FOB Price

Negotiable / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China		Brand Name	Feidiao
Model Number	WSH-A

WSH-A Wire Rope Pulling Hoist Features:
1)Capacity from 0.8T to 3.2T
2)High quality aluminium body
3)Overload protection

WSH-A Wire Rope Pulling Hoist Features:
1)Capacity from 0.8T to 3.2T
2)High quality aluminium body

3)Overload protection system ensures safety in operation

4)Tube handle length is adjustable, so it is very convenient to regulate the hand force according to the lifting force.

5)Widely used for lifting, pulling, tensioning, and tightening in many areas

6)Easy operation, convenient maintenance

7)Get Certificate of ISO9001

8)The static test is 4 times of capacity, and running test is 1.5 times of capacity.

Model	WSH-0.8A	WSH-1.6A	WSH-3.2A
Rated capacity t	0.8	1.6	3.2
Standard lift m	20	20	20
Test load t	1.2	2.4	4
Rated forward handpower N	341	400	438
Rope diameter mm	φ8.3	φ11	φ16
Rated forward travel(Swing it front and backward) mm	≥52	≥55	≥28
Net weight kg	6.4	12	23
