Container large ice block machine movable convenient for mobile market

Specifications

container large ice block machine
*CE approved
*Machine movable
*Brine-cooling,low cost
*Compact design,simple install



  Container large ice block machine movable convenient for mobile market

 CBFI MB Series Ice Block Machine Introduction:

1) Ice block is used to reduce temperature, especially in African country where the power is not stable and the climate temperature is high. When the power is off, people use the block ice to cool drinks and beverage and to keep fish fresh or crushed it into small pieces to fresh vegetable or fruit.

2)A Complete set of machine: compressor unit, cooling tower, water pumps, water pipes and water pipe fittings. Customers only need prepare power and water for running the machine.

3)Ice model Material: we use 304 stainless steel to produce ice cans for ice block machines.

Ice block machine models for your reference:



Item No.	Production	Rated Power	Circulating Water Pump Power	Cooling Water Pump Power	Cooling Fan Power	Machine Dimension	Weight of Machine
	Ton/24H	KW	KW	KW	KW	L*W*H	KG
MB10	1.0	3.92	2.2	1.5	0.37	2820*1410*965	900
MB20	2.0	7.11	2.2	1.5	0.55	1700*750*1500 2220*1440*1065	1100
MB30	3.0	9.68	2.2	2.2	0.75	1800*750*1500 3000*1380*1065	1300
MB40	5.0	12.56	4	2.2	0.75	2000*800*1600 3110*1470*1075	1500
MB50	8.0	14.6	4	2.2	1.5	2000*800*1600 4560*1380*1150	1700
MB60	6.0	18.84	4	2.2	1.5	2000*800*1600 5340*1380*1150	1900
MB80	8.0	21.30	4	4	1.5	2000*1000*1800 7720*1950*1150	2300
MB100	10.0	26.60	5.5	4	1.5	2500*1200*2000 6360*3710*1565	2700
MB150	15.0	48.30	7.5	5.5	2.2	3100*1200*2000 9280*2260*1560	3700
MB200	20.0	63	7.5	7.5	3.75	3500*1500*2200 11560*4200*1565	4700
MB250	25.0	68.7	7.5	7.5	3.75	3500*1500*2200 12080*2260*1560	5700
MB300	30.0	76.4	7.5	7.5	5.5	3500*1500*2200 11560*5430*1600	6700
MB400	40.0	126	7.5	7.5	7.5	2*3500*1300*2200 11560*7080*1600	8700
MB500	50.0	137.4	7.5	7.5	7.5	2*3500*1300*2200 14170*7080*1600	10700
MB1000	100.0	274.8	15	17	15	4*3500*1300*2200 12000*13500*1450	21400



 CBFI MB Series Ice Block Machine Features:

*Ice model design: the ice model has groove in two sides aiming to enhance the anti-deform ability for ice molds.

*Welding Craft: the vertical welding line is formed by automatic welding machine in one time. With this welding craft, there is no insufficient solder, no skip solder. Every ice maker of Icesource has no weld beading or no broken welding. It ensures enough strength to resist the expansibility generated during ice forming process.

The Advantages of containerized block ice machine:

1. It is installed in container, no need to build a building to place it.

2. It's moveable, it is very convenient for mobile market.

 10kg block ice:

If you are interested in our container large ice block machine, please contact us. We will get back to you within 24hours after getting your inquiry.



Note: in your inquiry, pls kindly inform me the information below:

1. What's the daily production of the machine do you want? We can offer from 1ton to 100ton.

2. What's the weigght for each ice block? We can design at 2.5kg, 5kg, 10kg, 15kg, 20kg, 25kg, etc.

3. What's your voltage for running the machine? Our standard one is 380V/3Phase/50Hz.



Thanks.
