Convinient Use CD Series Battery Charger

Name: Convinient Use CD Series Battery Charger
Brand: stonote ruiling
SKU: 120672981
Availability: InStock

Taizhou Shitong Welding Equipment Co., Ltd.

US$ 40 - 300 MOQ: 1 Piece

Key Specifications

Brand Name:

stonote ruiling

Model Number:

CD-320

Use:

Standard Battery

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Brand Name stonote ruiling

Model Number CD-320

Use Standard Battery

Place of Origin Zhejiang, China

Specifications

1. Modern design and high performance.
2. possibility of use in harsh conditions :IP23C
3. Choice of normal charging,quick

Packaging & Shipping

Company Information

1.Single -phase, charger of charging lead-acid battery 12/24V,equipped with ammeter

2. Various plug for choosing

3. possibility of use in harsh conditions :IP23C

4 Timer for quick charging.

ITEM	CD-320	CD-400	CD-500	CD-230
voltage (V)	220	220	230	220
Phase	Single phase	Single phase	Single phase	Single phase
Frequency(hz)	50	50	50	50
Rated input capacity(KW)	1/6.4	1.6/8	1.6/10	1/6
Start current(A)	180	240	300	120
Adjustment position	4	4	6	4
Charging voltage(V)	12/24	12/24	12/24	12/24
Efficiency charging current	45	60	75	30
Rated charging current	30	40	50	20
Max rated capacity	500	700	800	400
Min rated capacity	20	20	20	20
Fuse	13	16	20	10
Protection class	IP21S	IP21S	IP21S	IP21S
Insulation class	H	H	H	H
Gross weight(kg)	14.5	16	25	13
Dimension(mm)	620305250	620305250	620305250	320250575
