DIN9021 flat washer
- 100000 Piece / Pieces per Month
- Tianjin port; Qingdao port; Shanghai port
- T/T
Product Details
Place of Origin: | Tianjin, China | Brand Name: | DH | Model Number: | DIN9021 flat washer |
Standard: | Other, ANSI, ISO, DIN, GB, IFI, ART. JISB |
Product Description
The best quality and faith bring us the good market, such as USA, CANADA, BRAZIL, AUSTRALIA, UK, GERMANY, ITALY, SPAIN, TURKEY, ALGERIA, DUBAI, RUSSIA, UKRAINE, SINGAPORE, MALAYSIA etc. “Made in DUNHUI” in many Countries.
“DUNHUI” is your correct choice. Welcome to visit
1. DIN9021 flat washer
2. Specifications
Washer standard:-
DIN 934,985, 439, A563 DH,10S 2H,
Gr 4, Gr7, B8, B8M, A2,A4,
SS316L, B8, B8M
Washer, Materials:-
Carbon steel, stainless steel, F436M,
SS304, SS316L,
SPRING,TAPER, PLATE,SS316
4.6. CARBON STEEL,ASTM
a36, 8.8 ,b7, a307, a325, a490,
WASHERS Standard: DIN6798, DIN6797
Diameter: (mm)3.2-15
3. The main performance and parameters
SIZE | ID(MIN) | ID(MAX) | OD(MIN) | OD(MAX) | THINKNESS(MIN) | THICKNESS(MAX) | KGS/M |
M6 | 6.40 | 6.62 | 11.57 | 12.00 | 1.40 | 1.80 | 1.020 |
M8 | 8.40 | 8.62 | 15.57 | 16.00 | 1.40 | 1.80 | 1.830 |
M10 | 10.50 | 10.77 | 19.48 | 20.00 | 1.80 | 2.20 | 3.570 |
M12 | 13.00 | 13.27 | 23.48 | 24.00 | 2.30 | 2.70 | 6.270 |
M14 | 15.00 | 15.27 | 27.48 | 8.00 | 2.30 | 2.70 | 8.620 |
M16 | 17.00 | 17.27 | 29.48 | 30.00 | 2.70 | 3.30 | 11.30 |
M18 | 19.00 | 19.33 | 33.38 | 34.00 | 2.70 | 3.30 | 14.70 |
M20 | 21.00 | 21.33 | 36.38 | 37.00 | 2.70 | 3.30 | 17.20 |
M22 | 23.00 | 23.33 | 38.38 | 39.00 | 2.70 | 3.30 | 18.30 |
M24 | 25.00 | 25.33 | 43.38 | 44.00 | 3.70 | 4.30 | 32.30 |
M27 | 28.00 | 28.33 | 49.38 | 50.00 | 3.70 | 4.30 | 42.30 |
M30 | 31.00 | 31.39 | 55.26 | 56.00 | 3.70 | 4.30 | 53.60 |
M33 | 34.00 | 34.62 | 58.80 | 60.00 | 4.40 | 5.60 |
75.30 |
4. Production and testing process
5.Main products of the show and the packing and shipping
6.Quality and Safety:
We have a very strict and complete quality control system, which promises that goods we produced are always of the best quality, the enough inspectors to ensure that each product can meet the quality requirements of customers. We do the final inspection in own factory with ISO 9001:2008.
7. Advantages
1) We produce parts by ourselves, which makes more competitive price and faster delivery;
2) We provide OEM/ODM service and submit various styles, latest designs to our clients;
3) We have many customers from Southeast Asia, Africa, Middle East, North America, and South America;
4) We have standard testing report from ISO, SGS and GMC;
5) We have great experience on provide high quality service to clients;
6) Welcome to visit our factory.
8.Location:
DUNHUI has a convenient location at the city’s exporting business zone, Dongli District. We are only 9 km to Tianjin International Airport, and very close to major highways,TIANJIN port. We look forward to work with your business!
