Portable truck mounted water well drilling rig easy to move
USD $1 - $1
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Shanghai
- T/T Credit Card
You May Like
-
Wire line core drilling rig XY-8, large diameter core drilling rig original drilling rig manufacturers
-
XY-44MP water well drilling rigs,deep drilling rig equipment
-
water well drilling rigs for sale XY-8MP rig platform
-
XY-180YG 150m core drilling machine rig highly efficient
-
XY-1A mineral drilling rig, 30m to 200 m drilling depth
-
XY-180YG 180m core drilling machine rig high speed rotary
Product Details
| Place of Origin: | Chongqing, China | Brand Name: | Gold | Model Number: | XYC-200GT |
Product Description
Truck mounted drilling rig for sale XYC-200GT
Specification
| Item | Number | ||
| Drilling method | Rotary | ||
| Drilling depth | 200meter | ||
| Drilling hole diameter | 75mm-300mm | ||
| Power | 15 KW | ||
| 22HP | |||
| Rig working outside size | Length | 5995mm | |
| Width | 2060mm | ||
| Height | 7500mm | ||
| Rig weight | 1500kg | ||
| Drilling kelly | 53/59*4 meter | ||
| Drilling rod | 50mm | ||
| Drilling bit | 75mm-300mm | ||
| Spindle | 64,128,287,557 | ||
| Hoist | Hoist reel | 140mm | |
| Single lifting speed | 0.12,0.22,0.49,0.95 | ||
| Single lifting force | 24KN | ||
| Wireline capacity | 35 meters | ||
| Wireline size | 13mm | ||
| Mast | Loading capacity | 5T | |
| Mast height | 6m | ||
| Mast leg | 160×120×6 | ||
| Swivel | Max lifting force | 50KN | |
| Equiped hoise diameter | 50mm | ||
| Mud pump | Model | BW-160 | |
| Displacement | 160L/min | ||
| Working pressure | 1.3Mpa | ||
| Reciprocate times | 165 times/min | ||
| Truck | Model | OuLingZB1043LSDS | |
| Motor mode/ power | LN4D27E3/66KW | ||
| Seating capacity | 3+3 | ||
Main Types
1.Core Drilling Rig 2.Water Well Drilling Rig 3.Anchoring Drilling Rig
4.Down-the-hole Drilling Rig 5.Underground Drilling Rig 6.Horizontal Directional Drilling Rig
Packaging & Shipping
Our Company View
Project Site
