Help CenterLarge Diameter CORE Drilling Rig XY-5 for Mineral Exploration
Related Products
-
1000m Drill Depth Truck Mounted Drilling Rig XY-5T Portable Rough Terrain TruckUS$ 1 - 1MOQ: 1 Set -
Exploratory Truck Mounted Drilling Rig XY-5T NQ BQ HQ Size Core DrillingUS$ 1 - 1MOQ: 1 Set
-
Truck Mounted Drilling Rig XY-5T NQ BQ HQ Size Core DrillingUS$ 1 - 1MOQ: 1 Set
-
Popular Personal Use 80-100m Boring Machine PortableUS$ 1 - 2MOQ: 1 Set
-
Popular 30m-160m Home Use Portable Water Drilling RigsUS$ 1 - 2MOQ: 1 Set
Mineral exploration core drilling rig XY-5 is a new type of core drill which is developed especially to meet the need of various drilling process mainly in diamond drilling, the power machine of which can either be motor diesel engine.
1) The wider range of vertical drill speed can be set into many gears.
2) Large drilling torque, high strength and strong capacity of drilling.
3) Adopting the connecting rod reinforcement spring cramp, hydraulic loosen chuck which is off normally and carbide inserted pipe slips, the clamping can be with large force, longevity and high reliability.
4) Adopt hydromatic brake, the work is steady, safely, and keep the band-type brake life is long.
5) Choose the high quality general parts such as article brand automobile gearbox, clutch and universal power transmission shaft.
6) There is supervisory system (We install it according to user requirement).It can monitor the parameters as toque,drilling pressure,pump volume,pump pressure,speed and so on.
7) The power can choose motor and diesel engine.
| Engine | Name | Electrical motor | Diesel engine model |
| Type | Y250M-4B35 | R4105 IZLD | |
| Power (Kw) | 55 | 75 | |
| Speed (r/min) | 1480 | 1500 | |
| Chisel in the ability | Φ50 Drilling rod | Drilling depth >1600 m | |
| Swivel head | Spindle speed (r/min) | Clockwise: 41-1071 | |
| Contrarotate: 46144 | |||
| Spindle Max output-torque (Nm) | 5200 (69r/min) | ||
| Spindle diameter (mm) | 93 | ||
| circumvolve angle | 0-360º | ||
| Upgrade capacity (KN) | Rated:140 | ||
| Pressurizes the ability (KN) | Rated:96 | ||
| Pressurizes the ability (KN) | 600 | ||
| Hydraulic system | Type | Planetary Type | |
| Single-rope lifting-force (KN) | Max 55 | ||
| Single-rope lifting-speed (m/s) | 0.76-3.85 | ||
| Roll diameter (mm) | 300 | ||
| Steel cable diameter (mm) | 20 | ||
| Water brake | Work speed (rpm) | 700-1800 | |
| Single-rope balance speed (m/s) | |||
| Single-rope balance load (KN) | 55 | ||
| Hydraulic system | Type of oil pump | CBTL-F430/F410-AFH6 | |
| Displacement (ml/r) | 30+10 | ||
| System press (MPa) | 10 | ||
| Mobile oil cylinder stroke (mm) | 500 | ||
| Dimensions(L*W*H) (mm) | 3370*1150*1960 (including motor) | ||
| 3870*1115*1960 (including Diesel engine) | |||
| Weight (Kg) | 3500 | ||
Contact Name: Alvin Qin
Mobile Phone/Whatsapp: +86-13637882559
Skype: alvin_gold
FAX: 023-62940030
Tele: 023-62984891
Any of your requirements would be really appreciated ! Thanks.
1,Are you trading company or manufacturer?
We are absolutely professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, piling rig, etc. We provide comprehensive solution to many fields like geological survey, mining industry, electric power etc.
Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.
2,Are your products qualified?
Yes, our products all have gained ISO certificate, and we have specialized quality inspection department for checking every machine before leaving our factory.
3,How about your machine quality?
All of our machines hold the ISO, QC certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.
4,Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your worksite and provid the training for your staff.
5,What about the qaulity warranty?
We offer one-year quality warranty for machines' main body.
6,How long can you deliver the machine?
Generally, we can deliver the machine in 10 days.
