Steel Industrial Building Insulation
- 50000 Square Meter / Square Meters per Month
- Ho Chi Minh City Vietnam
- T/T
- High Quality Aluminum Foil Air Bubble Home Insulation From Manufacturers
- metal foil bubble insulation
- Foil Bubble Insulation For Metal Roof, Metal Roofing Insualtion
- Flame retardant bubble foil insulation
- Metal aluminum foil bubble heat insulation material for building/single or double bubble
- Aluminum Foil fireproof foam Insulation for construction
Product Details
Place of Origin: | Ho Chi Minh City, Vietnam | Brand Name: | Cat Tuong | Model Number: | P1 |
Product Description
Specifications
Heat insulation made of one external pure metalized layer covering a single core layer of polyethylene bubble air.
Cat Tuong Sound- Heat Insulation Material P1 Cat Tuong is composed of bubbles air made from polyethylene sandwiched between two layers of metalized and PE foil. The metalized foils are heat reflective and the bubbles air are heat and sound insulation.
It keeps buildings warm in winter and cool in summer.
It is strong, light weight, clean and does not degrade over time.
It is easy and fast to install- usually save up to 50% labor time.
It prevents about 90% of heat radiation, decreases the temperature by 12-22C inside compared to the metal roof.
It can be installed under the roof, between the walls, under the ceiling and the floor.
It is environmental friendly, energy saving, fire retardant and has no odor or toxicity.
It replaces the glass wool or rock wool which after a few years degrade, became dusty and unhealthy.
It is largely used in industrial and civil construction, warehouse, livestock…in Vietnam, Thailand, China, Australia, New Zeeland, United States…
It can also be used in other application that needs heat insulation such as bag…
Thermal reflective insulation made of one external metalized foil layers covering a single core layer of polyethylene bubble air . (Product is manufactured by USA standard).
Structure: Metalized foil/ bubble air bag/ white polyethylene layer.
Property |
Units |
Dir |
Value | |
Metalized foil thickness | µm | 8 | ||
Bubble air diameter | mm | 10 | ||
Reflectivity (ASTM - C1371) | % | 99.95 – 99.96 | ||
Emissivity (ASTM - C1371) | E | 0.04 | ||
Noise Reduction Coefficient (TCVN) | % | 50.8% | ||
Tensile strength, average (ASTM-D882 ) |
N/mm2 | Longitudinal | 0.9 | |
Transversal | 1.2 | |||
Elongation At Break, average (ASTM-D882) |
% | Longitudinal | 13.58 | |
Transversal | 11.74 | |||
Classification of Surface Spread of Flame (BS-476 :part 7) |
|
Class One | ||
Water Vapor Transmission (ASTM E-96) | g/ m2.day | 0.24 | ||
Fungal Resistance Test |
| No fungal growth | ||
Corrosion Resistance (Internal Test) | Conc.HCI | High Resistance | ||
Yield | g/m2 | 230 | 249 | |
Standard Roll size | m | 1.55m x 40m | ||
Nominal thickness | mm | 4.0mm (±0.3) | ||
Standard Roll Weight | Kg | 16kg(±0.5) |
