Home > Products > New Products > High-accuracy Ground Prospecting Radar, GPR System
High-accuracy Ground Prospecting Radar, GPR System
- 50 Set / Sets per Month
- Chongqing China
- T/T
You May Like
-
Digital Underground Metal Searching GPR System, Ground Prospecting Radar
-
Digital Ground Prospecting Radar For Underground Metal Finding
-
Ground Prospecting Radar, Underground Metal Finding GPR System
-
Digital Ground Prospecting Radar, GPR System
-
Au,Ag and other precious metal jewelry analyzer
-
Precious metal jewelry test XRF analyzer
Product Details
| Place of Origin | Chongqing, China | Brand Name | Gold | |
| Model Number | GZRD Series | Power | Electronic | |
| Usage | Other, ground prospecting radar |
Product Description
Typical Application:
Utility location
Tunnel lining detection & advanced prediction
Road quality inspection
Mining, Geology, Hydrological survey
Rebar & Cable detection
Dam inspection
Life detection
Geotechnical engineering
Concrete inspection
Archeology
Main Featrures:
The integrated design of host and antenna
Easy to use, no field installation
High reliability wireless communication
Easy-to-use interface，one-click parameter setting, perfect or the field operation
Main Specification:
Center frequency: 100M 200M 400M 600M 1GHz 1.6GHz
Pulse repeated frequency: 50kHz~250kHz
Time range: 0-800ns
Number of samples: 512-8192 samples/scan, user selectable
Scan rate: 1-480 scan/sec
Operating modes: Point mode, survey wheel, free run
Display modes: Pseudo color，stacked waveform or grey-scale
Operating temperature: -10℃-+70℃
Battery: Li-Ion (12V 10AH)
Wireless Communication: 802.11b/g/n,>25 m
Wired communication: RJ45 100BT Ethernet
Packing Detailes:
The product will be packed by customized wooden case, detailed dimension and weight information will be provided after packing.
Any question please feel free to contact:
Gold Tao
Cell: +86 15922982462
Tell: +86 23 62794421
Fax: +86 23 62940030
Skype: goldgeo
