qilu PVB interlayer is a macromolecule material molded by polyviny, butyral resin that is plasticized and extruded by plasticity. Our PVB film with excellent light transparency, heat and cold resistance, elasticity, is well-sticking to inorganic glass and the making of laminated safety glass. Usual thickness specification is between 0.2 mm - 2 mm.
qilu PVB interlayer is mainly used in making laminated safety glass. Laminated glass is a special glass which is inserted with PVB film between two layers of common glass, which under high heating temperature and pressure, binds to create a single construction. Because of PVB laminated glass with the function of safety, heat preservation, noise proof, and ultraviolet resistance, etc, it is widely used in areas such as high-rise building and auto. PVB film with special formula is also used in aeroplane, space flight ware, military instrument, solar battery, solar energy acceptor and so on.
No. | Classfication | 0.38mm | 0.76mm | |
1 | Appearance |
| ||
1.1 | Appearances | Achromatic or slinghtly yellow lucid film With velvet surface that has no scar or crease . | ||
1.2 | Dotted waste sundries and air buhbles |
| ||
| ≤0.05 | Allowed if exist separately | ||
| 0.05 | Not exceeding 8 places per film | Not exceeding 5 places per film | |
|
| Making marks Define an extanded 0.5 metar film per place Add one extra meter par place | ||
2 | Size |
| ||
2.1 | Thickness ( mm ) | 0.38±0.02 | 0.76±0.02 | |
2.2 | Uniformity | Horizontal thickness warp should not exceed 15um at a distance of 25mm; horizontal Ehickness warp Should not exceed 20um at a distance of 50cm. | ||
2.3 | Length tolerance (m ) | 0-5 | 0-2 | |
2.4 | Width tolerance ( mm ) | 0-20 | ||
3 | Moisture ( % ) | 0.4-0.6 | ||
4 | Extending intansion ( MPa ) | ≥20.0 | ||
5 | Ruplura extending rate (%) | ≥200 | ||
6 | Fograge (%) | <0.4 | ||
7 | Shrinking rate (60/15min) ( % ) | ≤12 | ||
