Product Details

Place of Origin	Guangdong, China		Brand Name	ACS
Model Number	android mobile usb arduino nfc reader/atm card skimmer-- ACR1256U

Product Description

android mobile usb arduino nfc reader/atm card skimmer-- ACR1256U

Features

l USB 2.0 Full Speed Interface PC connector

l Detacheable mirco USB cable reader connector

l CCID Compliance

l Smart Card Reader:

æ Read/Write speed of up to 424 kbps

æ Built-in antenna for contactless tag access, with card reading distance of up to 50 mm

(depending on tag type)

æ Support for ISO 14443 Part 4 Type A and B cards, MIFARE, FeliCa, and all four types of

NFC (ISO/IEC 18092 tags)

l Support Key Access Security Control

l Support Security Encryption Algorithm

æ RSA(up to 2048Bit)

æ DES/3DES

æ SHA1 and SHA256

l Support True Random Generator (Random Number Generator Rate 64kbps)

l Application Programming Interface:

æ Supports PC/SC

æ Supports CT-API (through wrapper on top of PC/SC)

l Built-in Peripherals:

æ User-controllable Bi-Color LED

æ User-controllable buzzer

l Direct USB Firmware Upgradability

l Compliant with the following standards:

æ ISO 18092

æ ISO 14443

æ CE

æ FCC

æ RoHS

Typical Applications

l e-Banking and e-Payment

l Transportation

l Network Security

l Access Control

l Personal transactions over the Internet

l Contactless Public Phones

l Vending machines

Technical Specifications

Universal Serial Bus Interface
Power Source.	From USB
Speed	12 Mbps(full speed)
Supply Votlage	Regulated5 V DC
Supply Current	200 mA (max.)
Contactless Smart Card Interface
Standard	ISO/IEC 18092 NFC, ISO 14443 Type A & B, MIFARE, FeliCa
Protocol	ISO 14443 T=CL for ISO14443-4 compliant cards and T=CL Emulation for MIFARE 1K/4K, ISO 18092, FeliCa and NFC tags
Operating Frequency	13.56 MHz
Operating Distance	Up to 50 mm (depending on tag type)
Smart Card Read/Write Speed	106 kbps, 212 kbps, 424 kbps
Physical Specifications
Dimensions	80.13 mm (L) x 50.06 mm (W) x 9.00 mm (H)
Weight	51 g (Device 25.5g and cable 25.5g)
Material	Acrylonitrile - Butadiene – Styrene (ABS)
Color	White
Antenna Size	54 mm x 34 mm
Cable Length	1.0 m (detacheable Micro USB Cable)
Built-in Peripherals
Bi-color LED	Red and Green
Buzzer	Monotone
Operating Conditions
Temperature	0 °C – 50 °C
Humidity	10% - 80%
Application Programming Interface	PC/SC CT-API (through wrapper on top of PC/SC)
Certifications/Compliance	ISO 18092, ISO 14443, CE, FCC, RoHS, USB Full Speed, VCCI
