Specifications

1.MC4 BRANCH ADAPTORS-T BRANCH CONNECTORS
2.Reliably performance
3.Simple,quick installation



MC4 BRANCH ADAPTORS-T BRANCH CONNECTORS 30A TUV SOLAR PANEL PV DIY-JJJK A

Model:   MC4-2293-JJJK



specification

Rated Voltage : TUV 1000V DC/ UL600V DC
Rated current : 20A-30A
Suitable cable cross section : 14AWG-10AWG
Pin dimension : Ø4.0mm
Proof voltage : TUV 6000V AC(1 MIN)/ UL 2200V DC (1MIN)
Polution degree : 2
Protection class : Class 2
Contact Material : Copper, Tin plated
Contact Resistance : ≤ 53
Degree of protection : IP 68
Withdrawal Force : ≥ 50N
Insertion force : ≤ 50N
Temprature range : -40 deg.~+85 deg.
Flame class : UL94V-0

Package included:

1pcs MC4 Branch Adapters Female to three Male









PAYMENT WAY

We accept Paypal,T/T, Western Union, and Escrow.



SHIPMENT

1. The parts from us are sure to have quality warranty,and they are double tested before shipping.
2. The items can be sent within 2 working day after the payment reaches us,except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/EMS/FedEx. Pls contact us directly and we will use your preferred ways.
4. Any import fees or charges are the buyer's responsibility. But we can help you reduce and avoid import taxes by declaring prices low, declaring the contents as "electronic accessories" or other items and shipping in simple packaging.



REFUND&REPLACEMENT

1. We can guarantee the product quality within 3 months.
2. If parts cannot work ,we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.





Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation.

 Please contact us if you have other requirement.

 Customer's requires are always welcome~!
