HD-1200Y cylinder engraving machine cnc router
- 200 Set / Sets per Month
- qingdao
- Credit Card
-
3 Axis Rotary CNC Macining
-
CNC wood cutting machine HD-1200 with rotary device
-
two-head heads craft cnc router hd-1313S
-
Cylinder Craft CNC Router HD-1200Y with rotary device
-
Cylinder Craft Wood Engraver HD-1200Y with XY working area 1200x200mm and Z working area 200mm
-
Cylinder craft wood engraver for wooden desk legs/stair
Product Details
| Condition: | New | CNC or Not: | CNC | Place of Origin: | Shandong, China |
| Brand Name: | Hongda Boke | Model Number: | HD-1200Y | Voltage: | AC380V50Hz |
| Power(W): | 2KW | Dimension(L*W*H): | 200*1200*200mm | Weight: | 500KG |
| Certification: | CE,ISO | Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
cylinder engraving machine cnc router:Two-way position rail high precision.Water-cool main axle with 2.2kw frequency convers
HD-1200Y Cylinder engraving machine cnc router
Technical parameter:
Model | HD-1200Y |
XY working area | 1200x200mm |
Z working area | 200mm |
Table size | 1710x530mm |
Max feeding | 4m-5.5m/min |
Work-holding | 2m-3m/min |
Resolution | 0.005mm |
Interface | USB |
Command | G code*.u00*.mmg*.plt |
Surroundings for software | Windows98/2000/xp |
Power(not include the spindle) | 500W |
Working voltage | AC220V/50Hz |
spindle power rate | 2.2KW |
spindle rotating speed | 0-24000rpm/min |
Drive motor | steper |
Features:
1. Servo rotation axis, high efficiency.
2. four axis control system with industrial PC , working steadily..
3. It can be used not for not only cylinder engraving, but also flat engraving. .
1.Whole steel structure, all round orbits, ball screw,
2. NC studio control system, Wentai Software Type3 Software,
3. 2.2Kw water cooling spindle,
4.20 cutters (φ3.175, φ4, φ6), 3 collets
1.Whole steel structure, all round orbits, ball screw,
2. NC studio control system, Wentai Software Type3 Software,
3. 2.2Kw water cooling spindle,
4.20 cutters (φ3.175, φ4, φ6), 3 collets
