3NB1300 MUD PUMP
- 8 Set / Sets per Month
- qingdao
Product Details
Place of Origin: | Shandong, China | Brand Name: | QINGZHOU PETROLEUM MACHINERY FACORY | Model Number: | 3NB1300 |
Theory: | Reciprocating Pump | Structure: | Piston Pump | Usage: | Oil |
Standard or Nonstandard: | Standard | Fuel: | Diesel | Pressure: | High Pressure |
Product Description
Specifications
1.RATED POWER:1300HP2.RATED SPEED:120
3.GEAR RATIO:4.194
4.SUCTION INLET :300MM DIA
5.DISCHARGE OUTLET:102MM DIA
SL3NB1300 Drilling mud pump is Triplex single action piston pump, the design characteristics is an optimization parameter, it can increase the stroke properly, lower the speed reasonably, improve the suction capability of the pump, prolong the service life of wearing parts The pump is used for oil-field and other industrial and mining establishments and for the drill, well workover and transporting the liquid media and mainly installed on 25-45 rig.
The series are produced and experimented according to SY5138 of the petroleum industry standard strictly.
SL3NB1300 Drilling mud pump technical parameter
Type | Triplex Single Acting Piston Pump |
Stroke Length: | 305 mm |
Rated power | 1300HP 956KW |
Suction inlet | Φ300 mm |
Rated speed | 120 SPM |
Discharge outlet | Φ102 mm |
Gear ratio | 4.194
| Weights | 20800 Kg |
Pump Speed (SPM) | Liner Size (mm) | ||||||||
130 | 140 | 150 | 160 | 170 | 180 | ||||
Theoretical Displacement (L/s) | |||||||||
120 | 24.27 | 28.16 | 32.52 | 36.18 | 41.52 | 46.54 | |||
100 | 20.23 | 23.46 | 27.1 | 30.15 | 34.6 | 38.78 | |||
90 | 18.21 | 21.12 | 24.39 | 27.13 | 31.14 | 34.90 | |||
MPa Pressure Rating | 34.3 | 30.5 | 26.6 | 23.4 | 20.7 | 18.5 |
Based on 90% mechanical efficiency and 100% volumetric efficiency.
