Refrigerator Condenser Refrigerator Parts Refrigerator Condensor

Specifications

Refrigerator condenser
steel tube coated with copper or zinc,cathode electrophoresis painting;bundy tube welded with steel wir

1.material: Bundy tube ( steel tube coated with copper) 4.76*450mm, 6.35*450mm, 4.76*500mm, 6.35*500mm, 4.76*600mm, 6.35*600mm;

2.structure: Bundy tube welded with steel wires;

3.paining: Cathode electrophoresis painting;

Spec. for Refrigerator Condenser:



Model	U	LxW(mm)	Qty/Ctn(pcs)	G.W./Ctn(kg)	Meas/Ctn(cm)	Qty/20HQ(pcs)	Qty/40HQ(pcs)
4U	4	360x250	10	7.37	49x57x8.2	12500	32500
5U	5	461x520	10	9.22	59x57x8.2	10200	26500
6U	6	562x520	10	11.06	69x57.8.2	8600	22500
8U	8	764x520	10	14.77	90.3x57x8.2	6600	17100
10U	10	966x520	10	18.48	110.5x57x8.2	5300	13800
11U	11	1067x520	10	20.34	120x57x8.2	4800	12600
13U	13	1269x520	20	24.09	140x57x8.2	4100	10700
15U	15	1471x520	10	27.74	161x57x8.2	3600	9300
