42u server cabinet
- 10000 Set / Sets per Month
- shenzhen
- T/T L/C D/P D/A Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | KTMP | Model Number: | KTMP-SF-13 |
Protection Level: | IP65 | Type: | Distribution Box | External Size: | Optional |
Product Description
42u server cabinet
Model: KTMP-SF-13
Specification :
Capacity | 42U |
Standard | Comply with ANS/EIA RS-310-D,IEC297-2,DIN4149,PART1,DIN41491 Standard; |
IP grade | IP20 |
Color | RAL9004, RAL9005, RAL7035 etc |
Thickness: | mounting profile: 2.0mm,mounting angle:1.5mm others: 1.2mm |
Material: | Nine-folded profiled(SPCC) |
Static Loading Capacity: | 1000Kgs |
Packing | assembled: plastic bag, then covering corrugated case, wooden case for optional |
Surface finish: | Degreasing, Pickling, Phosphating, Powder coated |
Door | Toughened glass front door |
Features :
1.Exquisite design with precise dimensions and craftsmanship
2.Aluminum frame, light weight and easy shipment
3.Toughened glass front door
4.High-density vented rear door
5.Removable side panel with lock or without for optional
6.Lockable and adjustable cable entry on the top cover and bottom panel
7.Adjustable feet and heavy duty castors are available at the same time
8.Supplied as a flat pack, easy to assemble
Details Show :
Main Component:
S/N | Specification | Quantiy | Material | Surface Finish | Remark |
1 | Top cover | 1 | SPCC cold rolled steel 1.2 | Power coated | --- |
2 | Fan unit | 1 | SPCC cold rolled steel 1.2 | Power coated | --- |
3 | Mounting angle | 6 | SPCC cold rolled steel 1.2 | Power coated | --- |
4 | Side panel | 2 | SPCC cold rolled steel 1.2 | Power coated | Removable steel door |
5 | frame | 1 | SPCC cold rolled steel 1.5 | Power coated | --- |
6 | Mounting profile | 4 | SPCC cold rolled steel 2.0 | --- | --- |
7 | Front door | 1 | 5mm toughened glass | Power coated | single vented |
8 | Advanced moon-shape lock | 6 | --- | --- | With 12 keys |
9 | Bottom panel | 3 | SPCC cold rolled steel 1.2 | Power coated | --- |
10 | M12 adjustable feet | 4 | --- | --- | --- |
11 | 2heavy duty castor | 4 | --- | --- | --- |
12 | Vented rear door | 2 | SPCC cold rolled steel 1.2 | Power coated | left and right |
Advantage :
1.Secure,firm and reliable
2. Easy to maintain equipment
3. Two Packing Ways:
1).Assembly packing to save labour cost, ready to resell or use
2).Disassembly packing to save space and transport cost, easy to assemble
4.Certification: ISO 9001:2000
5. OEM/ODM service available
Other Series :
Company Introduction :
Shenzhen KTMP Technology Company Limited is a professional sheet metal products
manufacturer . As a skilled manufacturer in sheet metal processing industry for 12 years , KTMP is a
company with the whole line of designing , producing , selling and trading a standard series of
products while continually making strides in new product development . Welcome to OEM all kinds of
network/ server cabinets .
Certification :
FAQ :
Your satisfaction is our greatest feedback.
Q:If OEM available?
A:Yes, we provide all of our products OEM.
Q:What are your company normal payment?
A:We accept L/C; T/T; D/P; D/A; Western Union;
Q: What are your company normal export terms?
A:We normally export with DHL EMS FedEX UPS and so on.
Q:Is sample available?
A:Sample is available.
