High Color Rendering Index CRI Ra90 60Volt 100lm/w Ceramic 10W COB LED

Name: High Color Rendering Index CRI Ra90 60Volt 100lm/w Ceramic 10W COB LED
Brand: SHINING
Availability: InStock

FOB Price

USD $0.06 - $0.6 / Piece

1 Piece(Min.Order)

Supply Ability 80000000 Piece / Pieces per Month
Port Shenzhen
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Model Number:	13.5*13.5 10W COB LED Chip	Chip Material:	InGaN	Emitting Color:	Cool White
Luminous Intensity:	.	Luminous Flux(lm):	900-1200 lmn	Optical Attenuation(%):	0.3
Power:	Other, 10W	Power Dissipation:	10000	Color Rendering Index(Ra):	80
Color Temperature:	6000-6500K	Operating Temperature(℃):	-20, 60	Storage Temperature(℃):	-40, 100
Place of Origin:	Guangdong, China	Brand Name:	SHINING	Certification:	CE

Packaging Details

Plastic tray normally.
Package can be customized on request

Product Description

High Color Rendering Index CRI 90Ra 60V 100lumen/w Ceramic 10W COB LED

Flip Chip LED COB Ceramic Plate Series
Item No.	Product Name	Power	CCT(K)	Luminous Flux{LM} @Typ.If)	Voltage(V)	Current (mA)	CRI(Ra)	Luminous Surface( MM)
SN-COB13.5	13.5*13.5	9w	2700-6500	810-990	54-57.6.6	150	>80	11.2
SN-COB13.5	13.5*13.5	10w	2700-6500	900-1100	60-64	150	>80	11.2
SN-COB19	19*19	10w	2700-6500	900-1100	36-38.4	300	>80	17
		15w	2700-6500	1350-1650	90-96	150	>80	17
		15w	2700-6500	1350-1650	36-38.4	450	>80	17
SN-COB1215	1215	6w	2700-6500	540-660	18-19.2	300	>80	10
		6w	2700-6500	540-660	36-38.4	150	>80	10
		8w	2700-6500	720-880	24-25.6	300	>80	10
SN-COB4046	4046	20w	2700-6500	1600-2000	30-32	700	>70	26
		30w	2700-6500	2400-3000	30-32	1050	>70	26
		50w	2700-6500	4000-5000	30-32	1750	>70	26
		70w	2700-6500	5600-7000	30-32	2450	>70	26

Flip Chip COB LED Aluminum Plate Series
Item No.	Product Name	Power	CCT(K)	Luminous Flux{LM} @Typ.If)	Voltage(V)	Current (mA)	CRI(Ra)	Luminous Surface( MM)
SN-COB13.5	13.5*13.5	3w	2700-6500	240-300	9-9.6	300	>80	11.2
		5w	2700-6500	400-500	15-16	300	>80	11.2
		7w	2700-6500	560-700	21-22.4	300	>80	11.2
		9w	2700-6500	720-900	27-28.8	300	>80	11.2
		12w	2700-6500	960-1200	36-38.4	300	>80	11.2
SN-COB19	19*19	10w	2700-6500	800-1000	30-32	300	>80	17
		15w	2700-6500	1200-1500	45-48	300	>80	17
		20w	2700-6500	1600-2000	60-64	300	>80	17
		25w	2700-6500	2000-2500	75-80	300	>80	17
		30w	2700-6500	2400-3000	90-96	300	>80	17
SN-COB2011	2011	3w	2700-6500	240-300	9-9.6	300	>80	10-11.2
		5w	2700-6500	400-500	15-16	300	>80	10-11.2
		7w	2700-6500	560-700	21-22.4	300	>80	10-11.2
		9w	2700-6500	720-900	27-28.8	300	>80	10-11.2
SN-COB2820	2820	3w	2700-6500	240-300	9-9.6	300	>80	17-20
		5w	2700-6500	400-500	15-16	300	>80	17-20
		7w	2700-6500	560-700	21-22.4	300	>80	17-20
		9w	2700-6500	720-900	27-28.8	300	>80	17-20
SN-COB6046	6046	15w	2700-6500	1200-1500	9-9.6	300	>80	46
SN-COB6046	6046	20w	2700-6500	1600-2000	15-16	300	>80	46
SN-COB7060	7060	15w	2700-6500	1200-1500	45-48	300	>80	60
		20w	2700-6500	1600-2000	60-64	300	>80	60
		30w	2700-6500	2400-3000	30-32	300	>80	60
SN-COB4046	4046	20w	2700-6500	1600-2000	30-32	700	>70	26
		30w	2700-6500	2400-3000	30-32	1050	>70	26
		50w	2700-6500	4000-5000	30-32	1750	>70	26
		70w	2700-6500	5600-7000	30-32	2450	>70	26

Applications of COB LEDs:

Competitive Advantages of our LEDs:

1. Good quality guarantee, 50000 hours lifespan, 2-3 years warranty.

2. Professional engineers and experienced workers.

3. Short delivery time, normally 2-6 working days.

4. Customized specifications available in CCT, CRI, Lumen, VF, Color , etc.

5. Various module type, such as SMD LED 2835 , 5630 , 3014 , 5730 , 7020 , 4014 ,

2323 , 3030 , 3535 , 1W high power LED , 1-300W integrated LED / COB LED, Diode etc.
