Place of Origin
Taiwan, China
Brand Name
GOLD APOLLO
Model Number
LRCM-R
POCSAG 8-Channel Relay Control Module
The best tool for industrial control, agricultural mechanical control and even your backyard garden.
Product Description
- Synthesized or Crystal Type
- Controlled through public paging system or POCSAG transmitter
- 8 Switch output for control 8 devices on/off and serial data out
- Antenna connection: Exteranl with SMA connect (option)
- Output speed: 4800, 9600bps
- Data Format: Numeric, Alpha, Binary
- 4 Channel Relays or 8 Channel Relays (option)
- The heavy duty Relays allows advanced users to control external devices for Facilities Maintenance, or the timers, garage door control.
- POCSAG / FLEX telemetry module
- 5 VDC Power Source
- A 5W transmitter TX-125EN can activate this RF receiving controller in distance of 5 kilometers away
- We offer basic software or creating your own software is welcomed
- This 4 or 8 channels multifunction RF receiving controller can be used to turn on/ off relays include fields of electronically operated gate, windows, Lifting Appliance, Switch, Lifter, Agricultural Control System, Industrial Control, Security Industry etc.
ADDITIONAL INFORMATION OF REALY :
- 1 pole 16 A, 1 form C (CO) contact
- Coil voltage: 12VDC
- Contact rating: 24VDC, 250VAC
- DC coil 530 mW
- 5kV/10mm coil-contact, reinforced insulation
- Ambient temperature 70°C (special applications 85°C))
- Flux proof
Additional Information
| Frequency | 168-174, 430-450, 450-470 MHz |
|---|---|
| Maximum Deviation | ±2.5 KHz / ±4.5 KHz |
| Harmonic Radiation | – 60 dBc or less -36dBm |
| Frequency Stability | ±3 ppm at –10°C ~ +60°C |
| Antenna | 50Ω SMA (F) |
| Data Interface | UART TTL |
| Prog. Interface | 2.5 earphone jack |
| Power Source | 5V DC |
| Dimension (mm) | LRCM :5.3(L) x 8(W) x 2(H), Relay onboard PCB (each piece): 13 x 6 x 3.1 CM |
| Weight | Approximately LRCM :65g, Relay onboard PCB (each piece) :87g |
KEY WORD: VHF radio module, UHF receiver module, VHFreceiver module
