Fully automatic Lead free wave solder machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port SHENZHEN
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Guangdong, China

Brand Name:

SAM

Model Number:

ZSW-350PC-B

Product Description

Specifications

1 Streamline designed exterior
2 applies to the current advanced lead free soldering technique
3 wave soldering

Feature:

1. Streamline designed exterior and all tempered glass overseeing window.

2.It applies to the current advanced lead –free soldering technique, suitable for SMT and through-hole lead-free soldering. 3.Windows XP operation interface and PCL control.

4.Flux spray nozzle self-cleaning system, auto-adjusting the spray speed & square according to the conveyor speed and PCB dimension.

5.Standard cool air knife after flux spraying and flux reclaim system to reduce the pollution of PCB and environments.

6.Special made conveyor rails to ensure no deformation; quick replacement titanium alloy fingers designed, convenient for replacement and maintenance.

7. Equipped with thermal compensation to enable temp. Dropped ≤2°C before entering soldering zone, reduced the thermal impact on components .

8.Solder dross auto-gathering function and patented anti-oxidization sleeve design to reduce the dross significantly.

9. Equipped with over-temp. alarm & protection, emergency quick-stop system and overioad protection for all motors.

Features of Machine:

	The quantity of heat compensatory unit for preheating; satisfy the high temperature demand in lead-free soldering guarantee the declined range of temperature from within 2°C		Titanium alloy solder bath suitable for lead-free solder.
	Auto supply flux system, buffer pump is anti-corrosion, buffer tank is sealed with limit liquid inspection. Flux spraying flux container can be exchanged on line.		Cooling system: with the cooling speed of 10°C/s or higher, fillet lifting effect on through-hope PCB can be reduced greatly and rough surface on solder joint in slow cooling can also be eliminated.

Model	ZSW-350PC-B
PCBWorking width	50~350mm
PCB conveyor height	Max.750±20mm
PCB conveyor direction	L→R(R→Loption)
PCB conveyor speed	0~2.0m/min
Conveyor angle	4~7°C
Preheating length	1900mm
Preheating zones quantity	3
Preheating temperature	250°C
Preheating power	14kw
Thermal compensation power	2kw
Suitable solder type	Lead-free/general solder
Solder Volume	600kg /550kg
The second wave height(max)	13mm
Solder temperature	300°C
Solder power	12kw
Temperature control	P.I.D
Solder Flux flow range	10~100ml/min
Cooler	10°C~20°C
Cooler	≤10°C
Power requirements	5w,3p)380v(220v option)
Power for heating up	Max.30kw
Power for operation	Approx.7kw
Air supply	5~7kg/cm²,150L/min
Weight	Approx.950kg
